6.3.7 XOR

The XOR (exclusive OR) output is 1 if the signal status of the inputs is different.
A block input that is not used (x) is assigned: x = 0.
Logic table of the XOR function:
Input 1
0
0
1
1

6.3.8 NOT

The output is 1 if the input is 0. The NOT block inverts the input status.
Advantage of the NOT, for example: xLogic no longer requires break contacts. You simply use a make
97
0 1
1 0
1 0
1 1
1 1
Input 2
0
1
0
1
1 0
0 0
1 0
0 0
1 0
(Symbol in xLogic)
Output
0
1
1
0
(Symbol in xLogic)
