A.2 Technical data: xLogic (ELC series)
Standard CPU
Units(ELC-6 series)
Inputs
of which can be used in
analog mode
Input/supply voltage
Permissible range
with signal "0"
with signal "1"
Input current
Outputs
Continuous current
Short-circuit protection
Switching frequency
Cycle time
Integrated time switches/
power reserve
Connection cables
Ambient temperature
Storage temperature
Degree of protection
Certification
Mounting
Dimensions
Programming cable
xLogic <=> xLogic
communication (RS485)
xLogic <=> network
(Ethernet)
Third party device(HMI)
273
ELC-6AC-R ELC-6DC-D-R
4 digital 4 digital
none none
110-240V AC 12-24V DC
85 ... 265 V AC 10.8 V ... 28.8 V DC
100 ... 253 V DC max. 3 V DC,1mA
max. 40 V AC 0.03 mA min. 8 V DC,1.5 mA
min. 79 V AC, 0.08 mA
2 relays 2 relays
10 A with resistive 10 A with resistive load;
load; 2 A with inductive load
2 A with inductive load
External fuse required External fuse required
2 Hz with resistive 2 Hz with resistive load;
load; 0.5 Hz with inductive load
0.5 Hz with inductive
load
< 0.1 ms/function < 0.1 ms/function
Yes / typ. 72 h Yes / typ. 72 h
2 x 1.5 mm² or 1 x 2.5 mm²
-20 to + 55 ºC
– 40 ºC to + 70 ºC
IP20
CE
On 35 mm standard mounting rail, 4 MW, or wall-mounting
W x H x D (48*90*64
mm)
PC cable, (RS232 or PC cable, (RS232 or USB)
USB)
No No
No No
Yes (modbus) Yes (modbus)
ELC-6DC-D-TN
4 digital
none
12-24V DC
10.8 V ... 28.8 V DC
max. 3 V DC, 1mA
min. 8 V DC,1.5 mA
2 transistors(PNP)
0.3 A
External fuse required
10 Hz
< 0.1 ms/function
Yes / typ. 72 h
PC cable, (RS232 or
USB)
No
No
Yes (modbus)
