Ts Sampling time,
duration of a time slice
TI Integral time
en
Loop error at the time n;
generally applies: e = SP –
PV
SP
PV
201
0 and kI = 1
If KC <> 0: kP = kI = KC
Fixed
Parameter TI, if you set this
parameter to 99:59 min, then you
switch off the I part of the controller.
Refer to SP and PV
The parameter SP is the set-value
assignment w. For this parameter you
can use the analog output of a
different special function.
PV is the process value x and is
calculated as follows:
PV = (analog value on input * gain) +
offset.
You can connect the input for
example by means of an analog input
with a PT100 sensor.
The gain parameter has an effect on
PV
The offset parameter has an effect on
PV
PV is restricted by the parameters
Min. and Max.
500 ms
00:01 min to 99.59 min
"
-10,000 to +20,000
"
0.0 to 10.0
-10,000 to +20,000
In each case: -10,000 to +20,000
