Easy Electronics xLogic Micro PLC User Manual page 57

Address 2:
Address 3:
Address 4:
Address 5:
Address 6:
Address 7:
Address 8:
The expansion port of CPU must be open when the using extensions . Following is tell
you how to open the expansion port:
You shall first select the FUNCTION PAGE. (Read 5.2)
1. Press or
2. Press OK key to confirm "Set adr":
3. Press or
4. Press OK key to confirm "Set E adr":
57
means the swith position
key to move the cursor to "Set address":
key to move the cursor to "Set E adr:.
