6.3 Basic functions list – GF
Basic functions represent simple logical elements of Boolean algebra.
You can invert the inputs of individual basic functions , i.e. the circuit program inverts a logical "1" at a
relevant input to a logical "0"; if "0" is set at the input, the program sets a logical "1".
The GF list contains the basic function blocks you can use for your circuit program. The following basic
functions are available:
View in the circuit diagram
91
View in xLogicsoft Name of the basic function
AND
AND with edge evaluation
NAND
（Not AND）
NAND with edge evaluation
OR
NOR
(Not OR)
