Chapter 1 General Introduction To Xlogic; Overview; Highlight Feature - Easy Electronics xLogic Micro PLC User Manual

1.1 Overview

xLogic is a universal logic module made by Easy.
xLogic , a compact, expandable CPU that can replace mini PLC, multiple timers, relays and counters,
Splitting the difference between a timing relay and a low-end PLC,
and calendar, and supports optional expansion I/O modules to enhance your control and monitoring
applications . Data adjustments can be done via the on-board keypad and LCD display, or with xLogicsoft.
It can be either DIN-rail or panel mounted, depending upon the needs of your application, and it is
available in 120V/240V ac as well as 12V and 24V dc versions, and it is the ideal solution for relay
replacement applications, simple control applications such as building and parking lot lighting, managing
automatic lighting, access control, watering systems, pump control, or ventilation systems in factory, and
home automation and applications in which cost is a primary design issue.

1.2 Highlight feature

4-lines, 10-characters per line, backlight display(16-characters per line for ELC-22/26 CPU).
l
Multiple value display and input via keypad and LCD display.
l
Key-panel programming feature (optional)
l
Function Block Diagram
l
Standard Modbus RTU/ASCII/TCP communication protocol supported.
l
It's optional for xLogic to act as slave or master in certain Modbus RTU communication network.
l
CAN BUS protocol based expansion modules(ELC-18/22/26 series CPU)
l
Expandable up to 9 linked IO expansion modules reaching 162 I/O points in maximum
l
1 RS232 port and 2 RS485 ports built-in (merely applied to standard ELC-12 Series); 1 RS232 port
l
and 1 RS485 port built-in (merely applied to ELC-18 Series)
Optional Ethernet connectivity
l
SMS/GSM module for remote control, monitoring and alarm
l
Multiple channels analog inputs available with DC 0-10V signal ,PT100 signal& 0/4....20mA.
l
Default Real Time Clock (RTC) and summer/winter timer is available
l
11

Chapter 1 General Introduction to xLogic

Each CPU houses a real-time clock
