Main Menu

The Main Menu provides six selections: Exit, Files, Macros, Upload, Download, and Utili-
ties. The Main Menu is shown in Figure 4-1 below.

Exit

Files
Xycom PKIM Utility: MAIN
Exit
Closes any open files and exits the utility.
exiting the other menus.

Files Menu

Files containing keypad macro sets (a macro for each key) may be saved on disk and
loaded into memory to view, edit, or download to the PKIM. Some of these files may be
included in the utility package for use in reconfiguring the keypads for different software
packages and as templates for defining completely new keypad macro sets. When Files is
chosen, a pull-down menu is displayed which offers the following choices: Open, Close,
Save, Save As, Delete, and Exit.
Command
Macros Upload
L-Arrow, R-Arrow, Enter
Figure Chapter 4 -1. Main Menu
Description
Chapter 4 - Programmable Keypad Utility Program
Download
can also be used for this purpose and for
ESC
Utilitie
s
4-3
