1. Disconnect all power supplies.
2. Remove the three screws that secure the top cover to the slide-out computer module.
Certain mounting configurations require the slide-out computer module to be re-
moved (refer to Removing the Slide-out Module section earlier in this chapter).
3. If present, remove the blank ORB from the slot that the 9000-RAD will occupy. Save
the screw.
4. Slide the card into the slot from which you removed the ORB. Push down on the
card evenly until it firmly seats into the card cage connectors.
5. Secure the RADAR ORB to the host system by replacing and tightening the screw
that was removed in Step 3.
6. Close the top cover and replace and tighten the three screws. If the slide-out com-
puter module was removed in Step 2, refer to the Re-installing the Slide-out Module
section earlier in this chapter.

Installing PC Boards

Check that the memory and I/O configuration of the board you want to install do not con-
flict with the CPU and I/O memory maps as outlined in your CPU board manual.
1. Disconnect all power supplies.
2. Remove the three screws that secure the top cover to the slide-out computer module.
Certain mounting configurations require the slide-out computer module to be re-
moved (refer to Removing the Slide-out Module section earlier in this chapter).
3. If present, remove the blank ORB from the slot that the PC board will occupy. Save
the screw.
4. Slide the PC board into an open slot in the backplane. Push down on the board
evenly until it firmly seats into the card cage connectors.
5. Secure the board by replacing and tightening the screw that was removed in Step 3.
6. Close the top cover and replace and tighten the three screws. If the slide-out com-
puter module was removed in Step 2, refer to the Re-installing the Slide-out Module
section earlier in this chapter.
12
Note
Do not force the boards or apply uneven pressure.
Note
Do not force the boards or apply uneven pressure.
