Startup; Utility Batch Mode; Main Menu - Xycom 3400 Series Hardware Reference Manual

ing utility commands. You can redefine all keys on the keypads. While the utility is run-
ning, the keypads are disabled.
Dialog boxes appear for user prompts and to display error and user advice messages.
Two keys allow you to exit the menus:
•
ESC
•
F1
sen to exit this menu.
Keys specific to each menu are shown at the bottom of each screen.

Startup

Type kputil to run the full keypad utility.

Utility Batch Mode

You can also use a batch file to reprogram keypads. This feature is useful if you wish to
reprogram many units with customized keypad macros without having to enter the full
keypad utility for each unit. Once the full utility has been used to create and save keypad
macros, the files containing these macros can be included on a disk with the keypad util-
ity and then used to reprogram other units from a batch file.
The command keypad filename runs the keypad utility batch mode. "Filename"
is the file containing the new keypad macros. The filename extension must be included.
For example, in a batch file, the command keypad def3408PC.pkm or
3408HMI.pkm would reprogram the keypad on the 3408KP with default values for the
numeric keypad. After programming, the system will reboot.

Main Menu

Table 5-1 illustrates the Main Menu.
Exit
Xycom KP Utility: MAIN L-Arrow, R-Arrow, Enter
63
moves to the previous menu or out of the utility from the Main Menu.
returns to the current menu headings in some of the menus where Exit can be cho-
Files Macros
Table 5-1. Main Menu
Upload Download Utilities
