3510/3510KP/3512/3512KP System Manual
Startup
Type. KPUTIL to run the full Keypad utility.

Utility Batch Mode

A mode is also available for reprogramming keypads from a batch file. This feature
is useful if you wish to reprogram many units with customized keypad macros
without having to enter the full Keypad utility for each unit. Once the full utility has
been used to create and save keypad macros, the files containing these macros can be
included on a disk with the Keypad utility and then used to reprogram other units
from a batch file.
The command Keypad filename runs the Keypad utility batch mode. Filename is the
file containing the new keypad macros. You must include the filename extension.
For example, the batch file KEYPAD def3512.pkm will reprogram the keypad with
def ult values.
a

Main Menu

The Main Menu is shown illustrated in. Figure 4-1. Each menu option is described in the next few
paragraphs.

Exit

Files
Xycom Automation KP Utility: MAIN L-Arrow, R-Arrow, Enter
Exit
Exit closes open files and exits the utility.
for exiting the other menus.
4-2
Macros Upload
Figure 4-1. Main Menu
ESC
Download
can also be used for this purpose and
Utilities
