Appendix C – Pinouts
This appendix describes the pinouts for the COM1, COM2, VGA, and parallel port con-
nectors.

COM1/COM2 Serial Port Connectors

The COM1 and COM2 serial ports are standard DB-9 connectors located on the I/O side
of the unit.

VGA Connector

The VGA is a 15-pin connector located on the CPU board. Refer to the CPU manual for
more information.
Table C-1. COM1/COM2 Serial Port Pinouts
Pin Signal
1 DCD
3 TXD
5 GND
7 RTS
9 RI
Table C-2. VGA Pinouts
Pin Signal
1 RED
2 GREEN
3 BLUE
4 ID2
5 GND
6 GND
7 GND
8 GND
Pin Signal
2 RXD
4 DTR
6 DSR
8 CTS
Pin Signal
9 KEY
10 GND
11 ID0
12 ID1
13 HSYNC
14 VSYNC
15 RSVD
