Running the Tests

To run the test, insert the diagnostics disk into drive A. Turn on the computer (the diag-
nostics program will boot up). Figure 2-2 shows the Main Menu as it is displayed on the
screen.
Copyright 1990-1994, Xycom, Inc. All rights reserved.
Diagnostic Tests Sequence/Selection Menu (Rel. xx)
0) WILL pause on an error
1) SINGLE PASS test mode
2) Save setup to file
3) Extract setup from a file
A) RAM Test
B) Video RAM Test
C) Extended RAM Test
D) Real Time Clock Test
E) COM1 Serial Port Test
F) COM2 Serial Port Test
G) COM3 Serial Port Test
H) COM4 Serial Port Test
I) Math Coprocessor Test
J) Video Adjustments Test
Use the letters to move the cursor and select/deselect, or use the arrow keys
to move, then use the [SPACE] key to select/deselect a test or
You can select tests individually. However, we recommend you use Auto-select (4)
which will select all the tests appropriate to your configurations.
Figure 2-1. Serial Loopback Connections
4)
5)
6)
7)
K)
L)
M)
N)
O)
P)
Q)
R)
S)
≡
[ENTER] = START TESTING
Figure 2-2. Main Menu
Auto-select tests
Deselect all tests
Quit and exit to DOS
Return to Previous screen
Video Interface Test
Speaker Port Test
LPT1: Printer Port Test
LPT2: Printer Port Test
C: Hard Drive Interface Test
D: Hard Drive Interface Test
A: Floppy Drive Interface Test
B: Floppy Drive Interface Test
Keyboard, Keypad Tests
= Test Selected
Chapter 2 - Testing
function:
