Codes
Displays a table of keys and their scan codes in Hex. See Codes section in this chapter
for a complete code listing.
Hex/Decimal
Toggles between displaying the scan codes in Hex and Decimal formats.
Insert
The insert key toggles between insert and overtype mode.

Upload Menu

Use the Upload Menu to choose which keypad macro information to load. Choices in this
menu are Function keypad, Numeric keypad, Keyboard, PKIM version, and Exit.
Command
Function Keypad
Numeric Keypad
Keyboard
PKIM Version
Exit
Only one macro set may reside in memory at one time. Also, Upload is not available if
the utility is started with the /r switch
A checksum will be calculated during transmission and an error message displays if an er-
ror occurs.

Download Menu

Any macro set previously programmed is overwritten when you select Download.
Chapter 4 - Programmable Keypad Utility Program
Description
Commands the PKIM to send its entire macro set for the
function key keypad.
Commands the PKIM to send its entire macro set for the
numeric key keypad.
Commands the PKIM to send its entire macro set for the switch
array keyboard. (The 9450 does not support the ability to
reprogram switch array keyboards. You may choose to upload a
keyboard, but the keys will not be defined.)
Commands the PKIM to send its firmware revision number.
Returns to the Main menu.
Note
Note
4-7
