3600 Series
Flat Panel Industrial PCs
User Manual for the
3612T, 3612KPM, 3612KPMT,
3615T, 3615KPM, & 3615KPMT
Models
© © © © 2004 XYCOM™ AUTOMATION, INC.
Printed in the United States of America

Advertisement

Table of Contents
loading

Related Manuals for Xycom 3600 Series 3612T

Summary of Contents for Xycom 3600 Series 3612T

  • Page 1 3600 Series Flat Panel Industrial PCs User Manual for the 3612T, 3612KPM, 3612KPMT, 3615T, 3615KPM, & 3615KPMT Models © © © © 2004 XYCOM™ AUTOMATION, INC. Printed in the United States of America...
  • Page 2 This document is copyrighted by Xycom Automation Incorporated (Xycom Automation) and shall not be reproduced or copied without expressed written authorization from Xycom Automation. The information contained within this document is subject to change without notice. Xycom Automation does not guarantee the accuracy of the information.

  • Page 3: Table Of Contents

    Table of Contents CHAPTER 1 – INTRODUCTION ...........................1 ..............................1 RODUCT VERVIEW ..............................1 TANDARD EATURES ..............................3 PTIONAL EATURES Front Panels ................................4 I/O Panel ................................8 Back Panel.................................10 Power Panel ..............................11 ............................12 NPACKING THE YSTEM ..............................12 UICK TARTUP CHAPTER 2 – INSTALLATION ..........................13 ............................13 NSTALLATION VERVIEW...
  • Page 4 3600 Series Flat Panel Industrial PC Table of Contents .................................39 TARTUP ................................39 Exit..................................40 Files Menu .................................40 Macros Menu..............................41 Upload Menu ..............................43 Download Menu ..............................43 Utilities Menu ..............................44 ............................44 TILITY ATCH ............................45 EYPAD ODES CHAPTER 4 – MAINTENANCE ..........................48 ........................48 ENERAL REVENTIVE AINTENANCE Fuse Replacement..............................48...
  • Page 5 3600 Series Flat Panel Industrial PC Table of Contents (LPT1) ........................66 ARALLEL ONNECTOR ............................67 ERIAL ONNECTORS COM1 ..................................67 COM2 ..................................68 VGA C ..............................68 ONNECTOR APPENDIX D – AIM3 CONTROLLER JUMPERS....................69 APPENDIX E – TSKAM JUMPER AND SWITCH SETTINGS ...............70 TSKAM B 1, P 141438-001 2 ....................70 OARD...

  • Page 6: Chapter 1 - Introduction

    Chapter 1 – Introduction Product Overview ® ® The 3600 series of flat-panel Industrial PCs combines an Intel Celeron ® Pentium III processor with a flat-panel display to offer a powerful, compact package for the factory floor and other harsh environments. These PCs feature an open architecture to meet a wide variety of applications that require both a powerful PC and a durable industrial enclosure.
  • Page 7 3600 Series Flat Panel Industrial PC Chapter 1 – Introduction ® ® ® Intel Socket 370 Celeron or Pentium III options up to 1.26GHz • • • • AGP video controller, 4 MB system video RAM, up to 32 MB available •...

  • Page 8: Optional Features

    3600 Series Flat Panel Industrial PC Chapter 1 – Introduction Additional standard features 3612KPM(T) & 3615KPM(T) models 40 relegendable function keys (80 with the F/A function) • • • • Numeric, PC control, and alpha keypads • • • • Windows start menu and pop-up menu keys •...
  • Page 9 3600 Series Flat Panel Industrial PC Chapter 1 – Introduction The 3600 series has a NEMA 4/4X/12 and IP65 sealed front panel. The panel protects the system’s interior when the system is properly panel-mounted. 3612T & 3615T Front Panel Figure 1-1. 3612T Front Panel 142214 (F)

  • Page 10: Front Panels

    3600 Series Flat Panel Industrial PC Chapter 1 – Introduction Table 1-1. 3612/15T Front Panel Feature Description Front Panel The front panel has four components: a display; strengthened glass covering the display; a frame in which the display and the glass are mounted;...
  • Page 11 3600 Series Flat Panel Industrial PC Chapter 1 – Introduction 3612KPM(T) & 3615KPM(T) Front Panel Diagnostic LEDs Brightness Keyboard/mouse and USB ports Mouse Figure 1-2. 3612KPM(T) Front Panel The 3612KPM(T) features function keys on either side of the flat panel display (PF1-PF20), function keys below the display (F1-F20), a numeric keypad, window keys, a cursor control keypad, diagnostic LEDs, industrial mouse/keyboard and USB ports.
  • Page 12 3600 Series Flat Panel Industrial PC Chapter 1 – Introduction Table 1-2. 3612/15KPM(T) Front Panel Feature Description Front Panel The front panel has four components: a display; strengthened glass covering the display; a frame in which the display and the glass are mounted;...

  • Page 13: I/O Panel

    3600 Series Flat Panel Industrial PC Chapter 1 – Introduction Figure 1-3. 3600 System I/O Panel 142214 (F)
  • Page 14 3600 Series Flat Panel Industrial PC Chapter 1 – Introduction Table 1-3. 3600 System I/O Panel Feature Description Parallel Port The parallel printer port (LPT1) is a DB-25 pin female connector. This port provides a standard PC-compatible printer interface. COM Ports COM1 is RS-232/485 compatible.

  • Page 15: Back Panel

    3600 Series Flat Panel Industrial PC Chapter 1 – Introduction Hard drive access CD-ROM drive Floppy drive Power connector and bracket Figure 1-4. 3600 System Back Panel 142214 (F)

  • Page 16: Power Panel

    3600 Series Flat Panel Industrial PC Chapter 1 – Introduction Voltage Selector Switch Power Connector (under retaining bracket) Fan & Filter Figure 1-5. 3600 Side Panel with Fan Filter and Power Connector Table 1-4. 3600 Power Panel Feature Description Power Connector This is a three-pin connector.

  • Page 17: Unpacking The System

    3600 Series Flat Panel Industrial PC Chapter 1 – Introduction Unpacking the System When you remove the system from its shipping container, verify that you have the parts listed below. Save the box and inner wrapping in the event you need to reship the unit.

  • Page 18: Chapter 2 - Installation

    Chapter 2 – Installation This chapter offers detailed installation instructions and outlines the options for the 3600 units. It also includes the guidelines for preparing your unit for installation and use. Installation Overview Warning For Hazardous Locations installation, review the Hazardous Locations Installation section in this chapter before startup.
  • Page 19 3600 Series Flat Panel Industrial PC Chapter 2 – Installation 5. Attach one end of the power cord to the power receptacle on the unit and the other end to a properly grounded 115/230 VAC, 50-60 Hz outlet. 6. Turn on power to the system. The system will boot-up the installed operating system.

  • Page 20: System Cutout Dimensions

    3600 Series Flat Panel Industrial PC Chapter 2 – Installation System Cutout Dimensions 3612T Figure 2-1. 3612T System Cutout Dimensions (inches [mm]) 142214 (F)

  • Page 21: 3612Kpm(T)

    3600 Series Flat Panel Industrial PC Chapter 2 – Installation 3612KPM(T) Figure 2-2. 3612KPM(T) System Cutout Dimensions (inches [mm]) 142214 (F)

  • Page 22: 3615T

    3600 Series Flat Panel Industrial PC Chapter 2 – Installation 3615T Figure 2-3. 3615T System Cutout Dimensions (inches [mm]) 142214 (F)

  • Page 23: 3615Kpm(T)

    3600 Series Flat Panel Industrial PC Chapter 2 – Installation 3615KPM(T) Figure 2-4. 3615KPM(T) System Cutout Dimensions (inches [mm]) 142214 (F)

  • Page 24: Power Management

    3600 Series Flat Panel Industrial PC Chapter 2 – Installation Power Management The following paragraphs explain the system power, the power supply, and the effects of excessive heat, electrical noise, and line voltage variation of the 3600 unit. Using isolation transformers on the incoming AC power line to the system is always a good practice.

  • Page 25: Excessive Heat

    3600 Series Flat Panel Industrial PC Chapter 2 – Installation Table 2–6. Available Expansion Current Maximum Available Current Voltage 3612 models 3615 models +3.3 VDC 1.58A 4.95A +5.0 VDC 3.40A 1.92A -5.0 VDC 160mA 190mA +12.0 VDC 0.58A 1.9A -12.0 VDC 160mA 190mA Caution:...

  • Page 26: Ac Power Cable

    3600 Series Flat Panel Industrial PC Chapter 2 – Installation In cases in which the installation is subject to unusual AC line variations, use a constant voltage transformer to prevent the system from shutting down too often. However, a first step toward the solution of the line variations is to correct any possible feed problem in the distribution system.

  • Page 27: Installing Internal Hardware Options

    3600 Series Flat Panel Industrial PC Chapter 2 – Installation Figure 2–12. Internal View of a 3600 AC Power Connector 4. Insert the three wire ends of the power cable into the hole of the connector plug. Bend the Protective Earth ground (PE) wire, the neutral (N) wire, and the line (L) wire around the corresponding screw.

  • Page 28: Dram And Additional Dram Dual Inline Memory Modules (Dimms)

    1. Create a folder named “Touch” on your desktop or in the root directory of your C: drive, and unzip the files into the folder. 2. Click on the file “setup.exe” and follow the directions. Xycom suggests that you accept all of the defaults.

  • Page 29: Calibrating The Touch Screen

    2. Run the file “install.exe” in the TB458 subdirectory and follow the directions. Xycom suggests that you accept all of the defaults. 3. Copy all of the batchfile utilities from the Batch Files subdirectory to C:\ 4.

  • Page 30: Custom Logo

    You have the option to place a custom label on the unit. Refer to Figure 2–6 for the dimensions and recommended requirements for a customized label. Once a customized label is procured, place the new label over the “Xycom Automation – Pro-face” label.

  • Page 31: Creating Custom Keypad Inserts

    3600 Series Flat Panel Industrial PC Chapter 2 – Installation Creating Custom Keypad Inserts You can customize your keypad with keypad inserts. Refer to Figure 2-7 and Figure 2-8 for insert dimensions and installation for the 3612KPM(T). Refer to Figure 2-9 and Figure 2-10 for insert dimensions and installation for the 3615KPM(T).
  • Page 32 3600 Series Flat Panel Industrial PC Chapter 2 – Installation Figure 2-8. 3612 KPM(T) Keypad Insert with Dimensions (F1 - F20) 142214 (F)
  • Page 33 3600 Series Flat Panel Industrial PC Chapter 2 – Installation Figure 2-9. 3615KPM(T) Keypad Inserts with Dimensions (PF1 – PF10) Note: The PF11-PF20 insert has the same dimensions 142214 (F)
  • Page 34 3600 Series Flat Panel Industrial PC Chapter 2 – Installation Figure 2-10. 3615 KPM(T) Keypad Insert with Dimensions (F1 - F20) 142214 (F)

  • Page 35: Hazardous Locations Installation

    Chapter 2 – Installation Hazardous Locations Installation Xycom Automation designed the 3600 series to meet the requirements of Class I and II, Division 2 Hazardous Locations applications. Division 2 locations are those locations that are normally non-hazardous, but could become hazardous due to accidents that may expose the area to flammable vapors, gases or combustible dusts.

  • Page 36: Safety Agency Approval

    3600 Series Flat Panel Industrial PC Chapter 2 – Installation The Xycom Automation systems have the following approvals: Underwriters Laboratories Inc., UL 1604 Standard for Safety. Electrical • • • • equipment for use in Class I and Class II, Division 2, and Class III hazardous (classified) locations.

  • Page 37: Definitions

    • • • • abnormal operation of machinery or equipment; or Combustible dusts of an electrically conductive nature may be present in • • • • hazardous quantities. Note Xycom Automation systems are not suitable for installation within Division 1 locations. 142214 (F)

  • Page 38: Division 2 Locations

    3600 Series Flat Panel Industrial PC Chapter 2 – Installation Note Electrical equipment cannot be installed in Division 1 locations unless they are intrinsically safe, installed inside approved explosion-proof enclosures, or installed inside approved purged and pressurized enclosures. " Division 2 locations are listed below: Class I volatile flammable liquids or flammable gasses are handled, processed, or •...

  • Page 39: Power Switch

    3600 Series Flat Panel Industrial PC Chapter 2 – Installation & The systems are designed for installation within a clean and dry enclosure for both ordinary and hazardous locations. The front panel meets the requirements of UL and CSA Type 4, 4X, and 12 enclosures. The enclosure used for Class I Hazardous Locations should have a minimum rating of Type 12 (NEMA 12, IP 5X).

  • Page 40: Communication Cable Interfaces

    3600 Series Flat Panel Industrial PC Chapter 2 – Installation & All communication cables should include a chassis ground shield. This shield should include both copper braid and aluminum foil. The D-sub style connector housing should be a metal conductive type (e.g., molded zinc) and the ground shield braid should be well terminated directly to the connector housing.

  • Page 41: Hazardous Locations Control Drawing

    = 10 uF = 10 uF = 16 uH = 4 uH 2. Selected Nonincendive Field Wiring Apparatus shall satisfy the following: Nonincendive Field Wiring Xycom Models 3612KPM and KPMT Apparatus And Models 3615KPM and KPMT ≥ ≥ ≤ cable ≤...

  • Page 42: Operation And Maintenance

    3600 Series Flat Panel Industrial PC Chapter 2 – Installation The systems have been designed for compliance with relevant spark ignition tests. However, please note that the workstation front panel contrast adjustment tactile switches and keyboard connector are the only make/break components intended to be exercised by the operator in the course of normal operation.

  • Page 43: Chapter 3 - Keypad Utility Program

    The keypad switch arrays are disabled while the keypad utility is running. Loading the Keypad Utility Note Xycom’s keypad utility will only run under DOS 3.2 or better. The keypad utility will not run in a Windows environment. The keypad utility is on the “Documentation and Support Library” CD that shipped with your computer.

  • Page 44: Using The Keypad Utility

    The keypad utility uses a menu bar and pull-down menu system. All menu bars are displayed across the top of the screen. “Xycom Automation KP3 Utility” and the current menu titles are shown at the bottom of the screen (see Figure 3-1).

  • Page 45: Exit

    Close Exit Save Save As Delete Exit Xycom Automation KP3 Utility: MAIN L-Arrow, R-Arrow, Enter Figure 3-1. Main Menu, showing first-level pull-down menus Exit closes any open files and exits the utility. can also be used for this purpose. works for exiting the other menus as well.

  • Page 46: Macros Menu

    3600 Series Flat Panel Industrial PC Chapter 3 – Keypad Utility Program reconfiguring the keypads for different software packages, and as templates for defining completely new keypad macro sets. & Note You must have a macro file in memory before the Macros Menu is available. To load a macro file, select the File/Open menu.
  • Page 47 3600 Series Flat Panel Industrial PC Chapter 3 – Keypad Utility Program Table 3-3. Macros Edit Menu Command Description Teach Allows you to record up to 105 keystrokes in a macro. When Teach is selected, a graphic representation of the keypad currently in memory displays. Menu bar choices are Exit, ASCII, and Click OFF.

  • Page 48: Upload Menu

    3600 Series Flat Panel Industrial PC Chapter 3 – Keypad Utility Program Table 3-3. Macros Edit Menu Command Description Edit/Paste Paste inserts a sequence of scan codes (which were saved in memory using Copy) into the macro. To paste a sequence of scan codes that were previously copied, position the cursor where you want the text to appear and then press 1.

  • Page 49: Utilities Menu

    3600 Series Flat Panel Industrial PC Chapter 3 – Keypad Utility Program macros, which become the new key definitions for the keypad. After the download is complete, the system will prompt the user to cycle power. & When the Utilities menu is selected, two choices are displayed: Factory Default, and Exit.

  • Page 50: Keypad Scan Codes

    3600 Series Flat Panel Industrial PC Chapter 3 – Keypad Utility Program Note The download.dld file was created after the last keypad programming process. This includes both new programming and reprogramming the keypad to the factory default settings. Keypad Scan Codes The utility’s default keypad keycodes are listed in the following table.
  • Page 51 3600 Series Flat Panel Industrial PC Chapter 3 – Keypad Utility Program Table 3-6. Default Keypad Keycodes 3612KPM(T) F/A Key LED Off (Function Mode) F/A Key LED On (Alpha Mode) 3615KPM(T) Description Keyboard Make Break Codes Keyboard Make Break Codes of Key Equivalent Codes...
  • Page 52 3600 Series Flat Panel Industrial PC Chapter 3 – Keypad Utility Program Table 3-6. Default Keypad Keycodes 3612KPM(T) F/A Key LED Off (Function Mode) F/A Key LED On (Alpha Mode) 3615KPM(T) Description Keyboard Make Break Codes Keyboard Make Break Codes of Key Equivalent Codes...

  • Page 53: Chapter 4 - Maintenance

    Chapter 4 – Maintenance The 3600 series is designed to withstand the harsh environment of the factory floor. Routine maintenance can help keep your system in good operating condition. Preventive maintenance consists of several basic procedures that will greatly reduce the chance of system malfunction. Schedule preventive maintenance along with the regular equipment maintenance to minimize down time.

  • Page 54: Recommended Hard Drive Preventive Maintenance

    Xycom believes it is important to keep our customers informed, to offer alternative solutions, and to provide all of our customers with the excellent service they deserve.

  • Page 55: Product Repair Program

    Xycom Automation’s Product Repair & Customization Department (PR&C) restores equipment to normal operating condition and implements engineering changes that enhance operating specifications. Xycom Automation tests products returned to Xycom with the standard Xycom test diagnostics. Follow the steps below to prepare the unit for shipment: 1.

  • Page 56: Front Panel Frame

    3600 Series Flat Panel Industrial PC Chapter 5 – Troubleshooting Front Panel Frame The 3612KPM front panel frame is made of polybutylene terephthalate polymers (PBT) resin. Certain combinations of chemical environments, temperature, and stress can adversely affect parts made from (PBT) resin. For this reason material that may come in contact with the 3612 unit should be carefully evaluated under end-use conditions for compatibility.

  • Page 57: Chemicals Compatible With 3 61 5 Frame

    3600 Series Flat Panel Industrial PC Chapter 5 – Troubleshooting 2 3 - 5 * 23 - . 4 $ Table 4-3 should be used only as a guide. Specific testing should be conducted to verify that the unit’s finish would meet the demands of extreme environments.

  • Page 58: Front Panel Overlay

    3600 Series Flat Panel Industrial PC Chapter 5 – Troubleshooting Front Panel Overlay The 3600 front panel polyester overlay may be adversely affected by combinations of chemical environments, temperature, and stress. For this reason, material that may come in contact with the 3600 unit should be carefully evaluated under end- use conditions for compatibility.

  • Page 59: Chapter 5 Troubleshooting

    Diagnostic Testing If you suspect that you are having hardware problems with your 3600 series, you can use the Xycom diagnostic utility to check out the PC’s various ports and subsystems. The diagnostic utility is on the Documentation and Support Library CD included with your unit.
  • Page 60 3600 Series Flat Panel Industrial PC Chapter 5 – Troubleshooting Figure 5-1. Serial Loopback Connections 142214 (F)

  • Page 61: Running The Tests

    To run the diagnostic tests, insert the DOS-bootable disk you created into drive A. Turn on the computer and the diagnostics program will boot-up. Figure 5-2 shows the Main Menu screen for the program. Copyright 2002, Xycom, Inc. All rights reserved. Diagnostic Tests Sequence/Selection Menu (Rel. xx) 1. WILL pause on error 5.

  • Page 62: Ms-Dos Reinstallation

    This procedure will destroy data that may exist on the hard disk drive. ® ® ® ® 8 9 # If you need to reinstall the Windows® 98 operating system, refer to the Xycom Automation Workstation Recovery Media Software Installation Instructions for Microsoft Windows 98 (shipped with systems preinstalled with Windows 98).

  • Page 63: Windows ® 2000 Reinstallation

    Chapter 5 – Troubleshooting ® ® ® ® . : : : # If you need to reinstall the Windows® 2000 operating system, refer to the Xycom Recovery for Xycom Automation Windows 2000 Workstation (shipped with systems preinstalled with Windows 2000). This document is devoted to the reinstallation of your Windows 2000 operating system and drivers, utilizing the Recovery Media provided with your Xycom Automation industrial computer.

  • Page 64: Installing Drivers

    Installing Drivers This section describes how to install the drivers associated with the system. Note For further assistance, contact Xycom Automation technical support at 734-944-0482 or support@xycom.com. " Video drivers and the expansion utilities are on the Documentation and Support Library CD included with the documentation kit.

  • Page 65: Touch Screen Drivers

    3600 Series Flat Panel Industrial PC Chapter 5 – Troubleshooting ) & * " If you have a touch screen driver that has been factory installed, you will also receive, pre-loaded and at no extra charge: MS-DOS®, Windows® 98, Windows® 2000, Windows®...

  • Page 66: Appendix A - Technical Specifications

    Appendix A – Technical Specifications Hardware Specifications Table A - 1 lists the hardware specifications for the 3612T, 3612KPM(T), 3615T and 3615KPM(T). Table A - 1. Hardware Specifications Specification Characteristic 3612 3615 Mechanical 3612T 3612KPM(T) 3615T 3615KPM(T) Height 11.20" Front Panel 12.45”...

  • Page 67: Environmental Specifications

    3600 Series Flat Panel Industrial PC Appendix A – Technical Specifications Table A - 1. Hardware Specifications Specification Characteristic 3612 3615 Regulatory 47 CFR, Part 15, Class A Compliance EN55022, Class A IMMUNITY EN61000–6-2 SAFETY EN60950 HARMONICS EN61000-3-2, Class A FLICKER EN61000-3-3 Environmental Specifications...

  • Page 68: Appendix B -Block Diagram And Aim3 Layout

    Appendix B –Block Diagram and AIM3 Layout Figure B - 1 shows the diagram of the AC Block Model; Figure B - 2 shows the layout of the AIM3 CPU board. AC Block Model FLAT PANEL DC/AC INVERTER FLAT PANEL INTERFACE DIMM MEMORY CONN.

  • Page 69: Aim3 Cpu Board Layout

    Appendix C – Pinouts AIM3 CPU Board Layout Figure B - 2. AIM3 CPU Board Layout w/Jumper & Connector Locations 142214 (F)

  • Page 70: Appendix C - Pinouts

    Appendix C – Pinouts This appendix provides the pinouts for the keyboard, mouse, LPT1, COM1, COM2, USB, and VGA connectors. NC indicates No Connection. Keyboard Port Connector The following table lists the signal definitions for the keyboard connector. It is a standard PS/2-compatible connector.

  • Page 71: Dual Usb Connector (Usb1)

    3600 Series Flat Panel Industrial PC Appendix C – Pinouts Dual USB Connector (USB1) The following table lists the signal definitions for the two USB connectors. Table C - 3. Dual USB Pinout Description Description 5VFUSE 5VFUSE USBP0– USBP1– USBP0+ USBP1+ Parallel Port Connector (LPT1) The following table shows the signal definitions for the DB-25 LPT1 connector.

  • Page 72: Serial Port Connectors

    3600 Series Flat Panel Industrial PC Appendix C – Pinouts Serial Port Connectors Serial ports RS-232 and RS-485 are supported. Only one connector can be used at a time. All termination is done outside the unit. Refer to the AIM3 manual for different RS-485 connectors.

  • Page 73: Com2

    3600 Series Flat Panel Industrial PC Appendix C – Pinouts COM2 The following table lists the signal definitions for the COM2 DB-25 connectors. Table C - 6. COM2 Connector Pinout RS-232 Signal Signal ORB_GND TXD2 RXD2 RTS2 CTS2 DSR2 DTR2 DCD2 PB_RESET VGA Connector...

  • Page 74: Appendix D - Aim3 Controller Jumpers

    APPENDIX D – AIM3 CONTROLLER JUMPERS Table D - 1 shows the position and function of the controller jumpers. Table D - 1. Controller Jumpers Jumper Position Function Not used – Not stuffed Provide ground return for +12V/+5V on COM2 connector Do not provide ground return for +12V/+5V on COM2 connector Allow high side alarm function on COM2 connector Do not allow high side alarm function on COM2 connector...

  • Page 75: Appendix E - Tskam Jumper And Switch Settings

    APPENDIX E – TSKAM JUMPER AND SWITCH SETTINGS Xycom Automation produced two different TSKAM boards for the 3600 units. To determine which TSKAM board is used with your unit check the jumper numbers on the board. If the TSKAM board has both JP12 and JP17 connectors present, it is TSKAM Board 2, Part Number 142430-001/2.

  • Page 76: Tskam Board 2, Part Number 142430-001/2

    3600 Series Flat Panel Industrial PC Appendix C – Pinouts TSKAM Board 2, Part Number 142430-001/2 Table E - 2 lists the jumper and switch settings for the TSKAM 2. Table E - 2. Jumper and Switch Settings for TSKAM 2 Switches/Jumpers Position/Setting Function...
  • Page 77 Index AC power cable DRAM..............23 constructing............21 Driver Access touch scre ens............ 23 floppy disk drive ..........11 Drivers keyboard port ............7 installing ............. 59 AIM3 miscellaneous ............ 60 jumpers .............. 69 touch screen ............60 Back panel ............. 10 video ..............
  • Page 78 3600 Series Flat Panel Industrial PC Index driver ..............59 Ports Jumper settings COM..............9 AIM3 CPU board ..........69 keyboard ............9, 65 TSKAM............70, 71 mouse ............9, 65 Keyboard parallel ............9, 66 connectors ............65 printer..............9 Keyboard port ............
  • Page 79 3600 Series Flat Panel Industrial PC Index System Power ............19 jumper settings..........70, 71 Testing switch settings..........70, 71 diagnostic............. 54, 56 Using the Keypad Utility......... 39 Touch screen drivers ..........60 Utility Batch Mode ..........44 Touch screens VGA connector............
  • Page 80 142214(F) Xycom Automation, Inc. Canada Sales: 905-607-3400 734-429-4971 Northern Europe Sales: +44-1604-790-767 Fax: 734-429-1010 Southern Europe Sales: +39-011-770-53-11 http://www.xycom.com...
