Summary of Contents for Xycom 1510
- Page 1 1510 Industrial PC Computer System Ó Ó Ó Ó 2001 XYCOM AUTOMATION, INC. Printed in the United States of America...
- Page 3 Windows is a registered trademark of Microsoft Corp. in the United States and other countries. Copyright Information This document is copyrighted by Xycom Incorporated (Xycom) and shall not be reproduced or copied without expressed written authorization from Xycom. The information contained within this document is subject to change without notice. Xycom does not guarantee the accuracy of the information and makes no commitment toward keeping it up to date.
- Page 4 EMC performance of this apparatus after system integrator/user installa- tion of PCB assemblies not manufactured and/or expressly tested and approved for compli- ance by XYCOM. It is the responsibility of the system integrator/user to ensure that installa- tion and operation of such devices does not void EMC compliance...
-
Page 5: Table Of Contents
Mounting the Unit..............................30 Safety Agency Approval ............................31 Preventive Maintenance............................33 Fuse Replacement ..............................34 Product Repair Program/Returning a Unit to Xycom ..................... 34 Hardware Specifications ............................35 Environmental Specifications ..........................36 COM1/COM2 Serial Port Connectors ........................37 VGA Connector ..............................37 Parallel Port Connector (LPT1) .......................... -
Page 7: Product Overview
Chapter One - Introduction Product Overview The 1510 Node Box PC Computer System offers a powerful, compact package for the factory floor and other harsh environments. The 1510 features an open architecture to meet a wide variety of applications that require both a powerful PC and a durable indus- trial enclosure. -
Page 8: Optional Features
1. Unplug the power cord on the rear of the 1510. 2. Remove the side panel. With the front of the unit facing you, lay the 1510 on its right side. Remove the eight screws that hold the left side panel in place (see figure 1-1). - Page 9 The Wake On LAN function will also be unavailable after reconfiguration. The only way to power the 1510 on or off is by connecting or disconnecting the power supply cord in the rear of the unit, or by using an external main power supply switch.
- Page 10 1510 Industrial PC Computer System Manual View of CN2 PINS STB5V PS ON PIN 1 PIN 3 PIN 2 CD-ROM Power Supply Floppy Drive Hard Drive Expansion Slots Processor CN7 PIN 16 & 18 and SBC-370 (under DRAM) I/O Ports DRAM Figure 1-2.
-
Page 11: Unpacking The System
Chapter One - Introduction Unpacking the System When you remove the 1510 from its box, verify that you have the parts listed below. Save the box and inner wrapping in the event you need to reship the unit. · 1510 unit ·... - Page 12 11. Turn on the power to the unit. Warning The 1510 has a momentary switch. To power the system up press and release the power switch. To power the unit off press and hold the power switch for 4 seconds until the system powers off, and then release.
-
Page 13: Preparing For The Tests
If any of these tests fail, either you do not have the correct default setting or there is a failure. Check the default settings and run the tests again. If another failure occurs, contact Xycom’s Product Repair & Customization De- partment (see Chapter 4). - Page 14 1510 Industrial PC Computer System Manual Perform the steps below before starting the system tests: 1. Set the CPU board jumpers and switches to the factory set positions. Refer to your CPU manual for these settings. 2. Plug the female end of the AC power cable into the rear of the unit and the male end into a properly grounded outlet.
-
Page 15: Running The Tests
To run the test, insert the diagnostics disk into drive A. Turn on the computer (the diag- nostics program will boot-up). The following figure shows the Main Menu. Copyright 1990-1996, Xycom, Inc. All rights reserved. Diagnostic Tests Sequence/Selection Menu (Rel. xx) 1. -
Page 17: System Components
Feature Description Power Supply The 1510 has a power supply of 235W AC, auto sensing, 50/60 Hz, 10.0 (max) @ 115V, 5.5 A (max) @ 230V Expansion Slots The 1510 has a 10-slot passive backplane with 4 full length ISA, three full length PCI, and one half length PCI available for expansion. -
Page 18: Front View
CMOS memory. Fan and Filter The 1510 has a fan and filter. The filter can be removed for cleaning (refer to the Fan Filter Cleaning section in Chapter 4 for more details). Reset Resets the 1510 system. -
Page 19: Back View
Figure 3-3. 1510 Back View Feature Description Expansion Slots The 1510 has a 10-slot passive backplane with 4 full length ISA, three full length PCI, and one half length PCI available for expansion. Two PICMG expansion slots are dedicated to the CPU. Ports The 1510 has two serial, one parallel, PS-2 keyboard and mouse, and VGA ports. -
Page 20: Ps/2 Keyboard And Mouse Connector
1510 Industrial PC Computer System Manual PS/2 keyboard and mouse connector Both a keyboard and a mouse can be connected to the PS/2 compatible port through the Y adapter cable included with your unit. Connect a mouse to the cable that has the mouse icon on it, and a keyboard into the cable that has a keyboard icon on it. -
Page 21: Dram And Additional Dram Single In-Line Memory Modules (Simms)
I/O memory maps in your CPU board manual. 3. Remove the side panel. With the front of the unit facing you, lay the 1510 on its right side. Remove the eight screws that hold the left side panel in place (see figure 1-1). -
Page 22: Reinstalling Operating Systems
MS-DOSÒ Ò Ò Ò reinstallation If you need to reinstall MS-DOS, refer to the Xycom Automation Workstation Recovery Media Software Installation Instructions for MicrosoftÒ DOS 6.22 (shipped with sys- tems pre-installed with MS-DOS). This document is devoted to the reinstallation of your MS-DOS operating system and drivers utilizing the Recovery Media provided with your Xycom Automation industrial computer. -
Page 23: Windowsò 95 Reinstallation
Chapter Three - Installation WindowsÒ Ò Ò Ò 95 reinstallation If you need to reinstall the WindowsÒ 95 operating system, refer to the Xycom Automa- tion Workstation Recovery Media Software Installation Instructions for MicrosoftÒ Windows 95 (shipped with systems preinstalled with WindowsÒ 95). This document is devoted to the reinstallation of your MicrosoftÒ... -
Page 24: Installing Drivers
1510 Industrial PC Computer System Manual Installing Drivers This section describes how to install the drivers associated with the 1510. Information about installing drivers for your computer is included in the Documentation and Support Library CD shipped with your computer, or on the web at www.xycom.com. -
Page 25: Cd-Rom Drivers
See the Documentation and Support Library CD, or the web address www.xycom.com, for drivers associated with Xycom equipment and software. Mounting Considerations This section describes issues you must address before placing the 1510 inside an enclosure. Consider the following points and precautions: ·... -
Page 26: Enclosures
On the average, the temperature within the 1510 is 7-10°C higher than that outside the enclosure. When the ambient (exterior) temperature reaches 42°C, the system’s power supply will begin to derate at a rate of 3.25 watts per increase of 1°C. The 1510 is rated to work at temperatures up to 50°C. -
Page 27: Excessive Heat
Chapter Three - Installation Excessive Heat The 1510 withstands operating temperatures from 0º to 50º C (32º to 122º F). To keep the temperature in range, the cooling air at the base of the system must not exceed 50°C. Allocate proper spacing between internal components installed in the enclosure. -
Page 28: Mounting Dimensions
KB/LK KB/LK KB/LK POW ER POW ER POW ER POW ER BRACKETS K/BOARD K/BOARD K/BOARD K/BOARD OPTIONAL FEET (WHEN NOT USING BRACKETS) 11.142 (283.00) 12.087 (307.01) 13.036 (331.11) 15.992 (406.19) 7.604 (193.14) Figure 3-5. 1510 Mounting Dimensions for Vertical Mount... -
Page 29: Mounting Brackets And Mounting Dimensions Horizontal Mount
SHELF OR PANEL MOUNT 12.992 (329.99) 6.763 (171.78) 6.970 (177.03) BRACKETS OPTIONAL FEET (WHEN NOT USING BRACKETS) 14.488 (367.99) 11.142 (283.00) 12.087 (307.01) 13.036 (331.11) 15.992 (406.19) 16.060 (407.92) 13.880 (352.55) 14.488 (367.99) Figure 3-6. 1510 Mounting Dimensions for Horizontal Mount... -
Page 30: Mounting The Unit
2. Refer to the Mounting Dimensions (figure 3.5 or 3.6) as a guide for mounting your system. 3. Mount and secure the 1510 unit, if required, using the mounting brackets. Refer to the section titled Securing the Mounting Brackets for information about attaching mounting brackets to the 1510. - Page 31 1510, secure the brackets to the unit, again referring to Mounting Dimensions figure 3.5 or 3.6 and figure 3.7. Mount the 1510, using the mounting brackets that you secured to the 1510 unit, to the shelf or panel where the unit will reside.
-
Page 32: Safety Agency Approval
1510 Industrial PC Computer System Manual Safety Agency Approval The Xycom 1510 is UL approved to meet the following standards: · Canadian Standards Association, Specification C22.2 No. 950 Information Technology Equipment (CUL recognized, File E181675) · Underwriters Laboratories Standard UL 1950... -
Page 33: Preventive Maintenance
Chapter Four - Maintenance Chapter Four – Maintenance The 1510 was designed to withstand the harsh environment of the factory floor. Routine maintenance can help keep your 1510 in good operating condition. Preventive mainte- nance consists of several basic procedures that significantly reduce the chance of system malfunction. -
Page 34: Fuse Replacement
1510 Industrial PC Computer System Manual Fuse Replacement The 1510 has no accessible fuse. Return the unit to Xycom for fuse replacement. Product Repair Program/Returning a Unit to Xycom Xycom’s Product Repair & Customization Department (PR&C) restores equipment to normal operating condition and implements engineering changes that enhance operat- ing specifications. -
Page 35: Hardware Specifications
C22.2, No. 950 Regulatory 47 CFR, Part 15, Class A Compliance EN55022: 1994 Class A IMMUNITY EN50082-2:1995 HARMONICS EN61000-3-2 FLICKER EN61000-3-3 SAFETY EN60950 ISO 9001 The manufacturing facility at Xycom, Inc. is ISO certified and is accredited by ANSI-RAB and the RvA. -
Page 36: Environmental Specifications
CD-ROM and standard hard disk drives should not be used in applica- tions where high levels of shock and vibration are present. If a CD-ROM drive is installed, the shock and vibration specifications of the 1510 are limited to the shock and vibration specifications of the CD-ROM drive. -
Page 37: Com1/Com2 Serial Port Connectors
Appendix B - Pinouts Appendix B – Pinouts This appendix describes the pinouts for the COM1, COM2, VGA, and parallel port con- nectors. COM1/COM2 Serial Port Connectors The COM1 and COM2 serial ports are standard DB-9 connectors located on the I/O side of the unit. -
Page 38: Parallel Port Connector (Lpt1)
1510 Industrial PC Computer System Manual Parallel Port Connector (LPT1) The parallel port connector is a 25-pin female connector located on the CPU board. Table B-3. Parallel Port Pinouts Signal Signal STROBE AUTOFEED PERROR INIT SELIN PACK PBUSY SELECT LAN RJ45 Connector (SBC-370 only) Table B-4. - Page 39 Index INDEX approvals, 30 dimensions, 28 BIOS setup menus, 13 operating systems CD-ROM drivers, 25 installation, 22 COM1 port, 35 optional features, 8 COM2 port, 35 options connectors Ethernet port, 19 PC/AT boards, 21 keyboard, 36 PCI boards, 21 parallel port (LPT1), 36 serial port, 35 parallel port (LPT1), 36 diagnostic testing, 13...
- Page 41 140412(B) Xycom Automation, Inc. Canada Sales: 905-607-3400 734-429-4971 • Fax: 734-429-1010 Northern Europe Sales: +44-1604-790-767 http://www.xycom.com Southern Europe Sales: +39-011-770-53-11...
