Startup
Type kputil to run the full keypad utility.
Utility Batch Mode
You can also use a batch file to reprogram keypads. This feature is useful if you wish to
reprogram many units with customized keypad macros without having to enter the full
keypad utility for each unit. Once the full utility has been used to create and save keypad
macros, the files containing these macros can be included on a disk with the keypad util-
ity and then used to reprogram other units from a batch file.
The command keypad filename runs the keypad utility batch mode. "Filename"
is the file containing the new keypad macros. The filename extension must be included.
For example, in a batch file, the command keypad def3512kpm.pkm would repro-
gram the keypad on the 3512KPM with default values for the numeric keypad. After
programming, the system will reboot.

Main Menu

Figure 4-1 illustrates the Main Menu.
Exit Files
Xycom Automation KP Utility: MAIN L-Arrow, R-Arrow, Enter
Exit
Exit closes open files and exits the utility.
exiting the other menus.
Macros Upload
Figure 4-1. Main Menu
ESC
Chapter Four–Keypad Utility Program
Download
can also be used for this purpose and for
Utilities
