9450 Industrial PC/AT Computer System

Preparing the System for Use

To prepare the system for use, perform the steps listed below. If you purchased any op-
tions, install them according to the instructions in the next two sections.
1. Connect the video cable to the 15-pin connector on the CPU board.
2. Connect the PWR/Key 15-pin cable to the PWR/Key female receptacle located
above the power receptacle.
3. Attach the power cord from the monitor to the power receptacle. Attach the power
cord power receptacle to a properly grounded 115/230 VAC, 50/60 Hz outlet. Attach
the power cord to the lower power receptacle.
4. Connect the touch screen.
If a touch screen has been factory installed, there is an AT adapter board plugged into
the backplane in slot 5. Connect the 9-pin cable from the monitor side to the 9-pin con-
nector in slot 5.
6. Press the ON/OFF switch to turn on power to the unit. The system will boot up at the
C: prompt if MS-DOS is properly installed on drive C.
7. Set the contrast and brightness controls on the back panel to the desired levels.
8. Install the application software via drive A located behind the access door on the
front panel.
The 8x14 character font set has been removed from the Quadtel BIOS used on the
AT4+ CPU board. This font set is now emulated to support most applications. If your
application does not display 8x14 characters correctly, install the TSRFONT.COM file.
