Command Description
View Lets you view, but not edit, the macro for the selected key. When View
is chosen, the Exit option and the state of the click (clicks are not
supported on the 9450) are displayed on the menu bar and a graphic
representation of the chosen keypad is shown. Select Exit from the
View Menu to return to the Macros Menu. To select a key to view, use
the arrow keys to position the cursor on the desired key and press
ENTER
ASCII line displays each keycode as the keys it represents on the full
stroke keyboard. Special labels are used for certain keys (e.g., Spc for
space bar, UAr for up arrow, and bk for the break code prefix). The code
line is displayed in either Hex or decimal, as explained below. There is a
one-to-one correspondence between the ASCII and code lines to help
interpret the code line.
While viewing the macro, the menu bar displays two options: Exit and
Hex/Decimal. Exit returns to the View Menu, while Hex/Decimal toggles
between displaying the macro in hex or decimal format. Default is Hex.
When Hex is chosen, the keycodes are displayed as hexadecimal value
scan codes. When Decimal is chosen, the keycodes are displayed as
the decimal equivalent of the hex codes.
For example, the macro abc would be displayed as 1C F0 1C 32 F0 32
21 F0 21 in hex, and 28 240 28 50 240 50 33 240 33 in decimal.
Teach Allows you to record up to 105 key strokes in a macro. When selected,
a graphic representation of the keypad currently in memory displays.
Menu bar choices are Exit, ASCII/Hex/Decimal, and Click ON/OFF. Exit
returns to the Macros menu. ASCII/Hex/Decimal chooses the format to
display the keystrokes as they are entered. Default is ASCII. Click is
not supported.
To select a key to define, use the arrow keys to position the cursor on
the desired key and press
records every key stroke on the external full-stroke keyboard in a macro
assigned to the chosen key. As the keys are entered they are displayed
using the chosen format.
Menu, so it is not a recordable key. However,
macro by using the editor. Changes made to the macros in the Teach
Menu are not programmed until you select Download.
Chapter 4 - Programmable Keypad Utility Program
. The macro is displayed as two lines—ASCII and code. The
ENTER
stops recording and returns to the Teach
ESC
. After a key is selected, the utility
can be included in a
ESC
4-5
