Appendix A – Technical Specifications

Hardware Specifications

Characteristic
Mechanical
Height
Width
Depth
Weight
Electrical
Power Supply
Backplane
Mounting
Monitor
Compatibility
CRT Size
Resolution
Dot trio pitch
Table A-1. 9450 Hardware Specifications
Specification
12.2" (310 mm)
19" (483 mm)
16.5" (419 mm)
60 lbs ( 27.2 kg)
115/230 VAC
3.3 A
50-60 Hz, 200 watts
150 Watts Derated
Seven-slot AT passive backplane (7 AT slots)
150 watts available to backplane/drives
+5 V @ 20 A/ 12 V @ 8 A
-5 V and -12 V: .5 A total
(Refer to Table 3-1 for Power derating)
Panel
VGA
14"
640 x 480, 800 x 600, 1024 x 768 (interlaced)
0.28 mm

Appendix A - Technical Specifications

A-1
