1. Locate a position for your 9450 that meets the specifications required (see previous
sections and Appendix A).
2. Add the cutout (as shown in Appendix B) to the enclosure.
3. Make sure the area around the cutout is clean and free from metal burrs.
4. Use proper grounding techniques. Establish a ground path from the 9450 chassis to
the enclosure chassis.
To make a proper ground, scrape paint off the inside of the enclosure panel around
mounting stud holes (in at least two places) at opposing ends of the unit. This insures
that a good electrical connection is made between the chassis and the grounded metal
panel.
5. Detach the slide-out computer module (see the Removing the Slide-out Computer
Module section earlier in this chapter).
6. Install the monitor portion of the unit into the cutout.
7. Reattach the slide-out computer module (see Re-installing the Slide-out Computer
Module section earlier in this chapter).
8. Tighten the 14 #10 nuts to 27 inch pounds.

Available Power

The 9450's expansion power is limited, as shown in Table Chapter 3 -1.
Voltage
+5 VDC
+12 VDC
-12 VDC
-5 VDC
20
Table 3-1. 9450 Available Current
Available Current
486 or AM5x36 Processors
Amps Watts
17.5 87.5
4.75 57.0
.49 2.45
.45 5.4
Total Not to Exceed 134 watts
Note
Available Current
Pentium Processors
Amps Watts
15.0 75.0
4.75 57.0
.49 2.45
.45
Total not to exceed 121 watts
5.4
