User Interface; Interface Controls; Figure 5 Xtc601 Application Software; Figure 4 User Interface - Michell Instruments XTC601 User Manual

OPERATION
2.3

User Interface

2.3.1

Interface Controls

The diagram above illustrates the user interface, which consists of a backlit Liquid
Crystal Display and 4 touch-sensitive pads that facilitate user interaction through the
glass of the enclosure.
All versions have Application Software to monitor or adjust parameters.
6
XTC601-EX1
Thermal Conductivity Analyzer
ESC
ENTER
Up/Down
ESC ENTER
Arrow
Button
Buttons
User Interface
Figure 4
Figure 5 XTC601 Application Software
XTC601 User's Manual
Backlit LCD
