APPENDIX D
Addr Function
40 Cal Ref3
41 Cal Ref4
42 Cal Ref5
43 Cal ADC1
44 Cal ADC2
45 Cal ADC3
46 Cal ADC4
47 Cal ADC5
48 mAINPUT1 4mA Cal point
49 mAINPUT1 20mA Cal point
50 mAINPUT2 4mA Cal point
51 mAINPUT2 20mA Cal point
52 mAOUTPUT1 4mA Cal point
53 mAOUTPUT1 20mA Cal point
54 mAOUTPUT2 4mA Cal point
55 mAOUTPUT2 20mA Cal point
56 CH2 output zero
57 CH2 output span
58 Last Cal Date DATE/MONTH
Last Cal Date: Field or Factory (bit 15) /
59
YEAR (bits0-3)
PCB Tempr Offset (for MSP430 Int Tempr
60
only) – NOT USED in latest f/w
61 Spare
62 Spare
63 Hours Of Operation
Restore Factory Settings / Cal data
64
(write 5491 to this reg)
65 Set Clock HRS
66 Set Clock MIN
67 Set Clock DAY
68 Set Clock MONTH
69 Set Clock YEAR
70 % Reading of Gas
71 Spare
72 Cell Temperature
73 PCB temperature (from MSP)
74 Spare
75 mA1 Input in % (comp signal)
76 mA2 Input (ext sensor signal)
77 Status Flags register
78 Clock HOURS/MIN
79 Clock SEC/DAY
80 Clock MONTH/YEAR
81 % MINIMUM (stats)
82 % MAXIMUM (stats)
50
XTC601 User's Manual
Access Ranges/Resolution
R 0.00-100.00
R 0.00-100.00
R 0.00-100.00
R 0-8191
R 0-8191
R 0-8191
R 0-8191
R 0-8191
R 0-8191
R 0-8191
R 0-8191
R 0-8191
R 0-8191
R 0-8191
R 0-8191
R 0-8191
Instrum range min to CH2 output
R/W
span, 0.01
CH2 output zero to instrum range
R/W
max, 0.01
R 1-31/1-12
R 0=Factory, 1=Field / 0-99
R -100/+100 C
R 0-65535
W 5491
W 00-23
W 00-59
W 01-31
W 01-12
W 00-99
R -199.00-199.99%
R -99.9-99.9 or equiv in F or K
R -99 to 99 C or equiv in F or K
R 0.0-100.0%
R See Reg Details
R 0-65535
R 00-23 / 00-59
R 00-59 / 01-31
R 01-12 / 00-99
R -199.00-199.99%
R -199.00-199.99%
97400 Issue 3.1, January 2017
Type
G
G
G
A
A
A
A
A
A
A
A
A
A
A
A
A
G
G
J
J
K
A
A
J
J
J
J
J
G
F
K
F
F
I
J
J
J
G
G
