APPENDIX E
Appendix E Modbus Register Map (HCG version)
Compatible with XTP601 Firmware Version: V1:03
NOTE: Addr+1 for Wintech Modbus Activex Control
Addr Function
0 Modbus Instrument Address (ID)
1 Settings Register
2 Display Contrast / Brightness
Units Register (Tempr, Pressure,
3
Ext Sens, Param, etc)
4 Chart Interval
5 Phase 1 Alarm 1 Set point
6 Phase 1 Alarm 2 Set point
7 Range 1 Zero (Ch1 output zero)
8 Range 1 Span (CH1 output span)
9 Phase 2 Alarm 1 Set point
10 Phase 2 Alarm 2 Set point
11 Range 2 Zero (Ch1 output zero)
12 Range 2 Span (Ch1 output span)
13 Phase 3 Alarm 1 Set point
14 Pase 3 Alarm 2 Set point
15 Range 3 Zero (Ch1 output zero)
16 Range 3 Span (Ch1 outpit span)
17 Cal Table 1 Ref 1
18 Cal Table 1 Ref 2
19 Cal Table 1 Ref 3
20 Cal Table 1 Ref 4
21 Cal Table 1 Ref 5
22 Cal Table 2 Ref 1
56
APP Ranges/
SW Resolution
R/W 1-127
R/W 0-65535
0-100% / 0-100%,
R/W
10% steps
R/W See reg details
2-60 Sec, in 2 sec
R/W
intervals
Instrum range min
R/W Instrum range max,
0.01
Instrum range min
R/W Instrum range max,
0.01
R 0.00 to Range Span
Range Zero to
R
100.00
Instrum range min
R/W Instrum range max,
0.01
Instrum range min
R/W Instrum range max,
0.01
R 0.00 to Range Span
Range Zero tp
R
100.00
Instrum range min
R/W Instrum range max,
0.01
Instrum range min
R/W Instrum range max,
0.01
R 0.00 to Range Span
Range Zero to
R
100.00
R 0.00-100.00
R 0.00-100.00
R 0.00-100.00
R 0.00-100.00
R 0.00-100.00
R 0.00-100.00
97400 Issue 3.1, January 2017
XTC601 User's Manual
Firmware
Type
definition
A INST_ID
B SET_FLAGS
C CONTR_BRIGHT
D UNITS
A CHART_INTERVAL
G PHASE1_AL1
G PHASE1_AL2
G XTC1_LO
G XTC1_HI
G PHASE2_AL1
G PHASE2_AL2
G XTC2_LO
G XTC_HI
G PHASE3_AL1
G PHASE3_AL2
G XTC3_LO
G XTC3_HI
G CAL_XTC1_REF1
G CAL_XTC1_REF2
G CAL_XTC1_REF3
G CAL_XTC1_REF4
G CAL_XTC1_REF5
G CAL_XTC2_REF1
