XTC601 User's Manual
1.2
Applications
The XTC601 binary gas analyzer is designed for use in process environments.
A sample system may be required to ensure that a clean, dry gas with no particles
or oil-mist is delivered to the XTC601. This will ensure the sensor is not damaged or
contaminated by the process. Michell Instruments is able to supply a quotation for such
a system.
Examples of applications include:
•
H
generator cooling systems (Power Generation)
2
•
H
in heat treatment furnaces (Metals)
2
•
CO
in fermentation process (Food)
2
•
CO
in biogas
2
•
Ethylene Oxide sterilization process (Food)
•
H
in blast furnace top gas (Steel)
2
•
H
in hydrocarbons (Petrochemical)
2
•
He recovery (Industrial Gas)
•
N
in CO
2
1.3
O-Ring Selection
The XTC601 has only one elastomeric seal in the gas path. There are 3 types of O-rings
available to offer greater flexibility with material compatibility. The Viton O-ring is fitted
as standard. The Ekraz O-ring is available for solvent resistance. For extremely low
temperatures there is a closed cell Silicone O-ring.
To comply with Hazardous Area certification, the material used in the EX1 & EX3 versions
is dependent on the lowest ambient temperature of the area the units are to be installed
in:
Ambient operating range:
-40°C to +55°C (-40°F to +131°F)
-15°C to +55°C (+5°F to +131°F)
-10°C to +55°C (+14°F to +131°F)
Michell Instruments
(Industrial Gas)
2
(for Silicone O-ring)
(for Viton O-ring) - Standard
(for Ekraz O-ring)
INTRODUCTION
3
