APPENDIX E
Register Type K: -32767 to +32767
15 14 13 12
r/w r/w r/w r/w
Range = 0 to 65535 represents values
Conversion: (RegValue - 32767)
Register Type L: Alarm Configuration
15 14 13 12
r/w r/w r/w r/w
Bits HEX
0, 1 0003
2, 3 000C
4, 5 0030
6, 7 00C0
8, 9 0300
10, 11 0C00
62
11 10 9 8
r/w r/w r/w r/w
11 10 9 8
r/w r/w r/w r/w
Meaning
Phase 1, Alarm 1 type - 00=OFF, 01=LOW, 10=HIGH
Phase 2, Alarm 1 type - 00=OFF, 01=LOW, 10=HIGH
Phase 3, Alarm 1 type - 00=OFF, 01=LOW, 10=HIGH
Phase 1, Alarm 2 type - 00=OFF, 01=LOW, 10=HIGH
Phase 2, Alarm 2 type - 00=OFF, 01=LOW, 10=HIGH
Phase 3, Alarm 2 type - 00=OFF, 01=LOW, 10=HIGH
XTC601 User's Manual
7 6 5 4
r/w r/w r/w r/w
7 6 5 4
r/w r/w r/w r/w
97400 Issue 3.1, January 2017
3 2 1 0
r/w r/w r/w r/w
3 2 1 0
r/w r/w r/w r/w
