APPENDIX F
Appendix F Hazardous Area Certifi cation
The XTC601-EX Thermal Conductivity Analyzer is certified compliant to the ATEX
Directive (94/9/EC) and IECEx for use within Zone 1 & 2 Hazardous Areas and has been
assessed so by SIRA Certification (Notified Body 0518).
The XTC601-EX Thermal Conductivity Analyzer is certified compliant to the North
American Standards (USA and Canada) for use within Class I, Division 1, Groups B, C
and D Hazardous Locations and has been assessed so by cCSAus.
F.1

Product Standards

This product conforms to the Standards:
EN60079-0:2012/A11:2013
EN60079-1:2007
EN60079-31:2014
CSA C22.2 No 0-10
CSA C22.2 No 30-M1986 (R 2007)
CSA C22.2 No 142-M1987 (R 2009)
F.2 Product Standards
This product is attributed with the product certification codes:
ATEX & IECEx
II 2 GD Ex d IIB+H2 T3 Gb
Ex tb IIIC T137°C Db IP66 T amb -40°C to +55°C
North American
Class I, Division 1, Groups B, C, D
F.3 Global Certifi cates/Approvals
ATEX
IECEx
cCSAus
TC TR Ex
These certificates can be viewed or downloaded from our website at:
http://www.michell.com
F.4

Special Conditions

1. Cable entry holes shall be fitted with either an appropriately certified
cable gland or appropriate certified blanking element. These shall provide
and maintain a minimum enclosure ingress protection of IP66.
2. The maximum pressure associated with the process medium in the
internal pipes shall be limited to 4 bar.
3. The maximum temperature associated with the process medium shall be
limited to 55°C.
64
SIRA 13ATEX1087X
IECEx SIR 13.0041X
2609575
RU C-GB. ГБ05.B.00152
XTC601 User's Manual
IEC60079-0:2011
IEC60079-1:2007
IEC 60079-31:2008
UL 916
UL 1203
97400 Issue 3.1, January 2017
