XTC601 User's Manual
• Chart duration in seconds = (Chart interval * 60).
• Chart data is only stored in volatile memory and therefore is not saved.
Chart interval is saved and available in a Modbus register.
• Chart data is not available via serial comms or in the blind unit as the
Application Software is able to perform more sophisticated charting functions.
NOTE: This data is not available via the Modbus
2.5.3

Secondary Parameters Page

Parameter Description
CELL T
PCB TEMP
COMP I/P
(standard version
only)
PHASE I/P
(HCG version
only)
EXT I/P
Michell Instruments
CELL T, °C
PCB TEMP, °C
COMP I/P
EXT I/P
Figure 13
Sensor cell temperature display in set unit (°C, °F or Kelvin)
Display Resolution = 0.1
Temperature display of Microcontroller in selected temperature unit
This gives an indication of the internal GUB temperature
Display Resolution = 1 unit
Accuracy = ±2ºC
The value of compensation input (mA i/p channel 1) as a %
(4 mA=0% and 20 mA=100%)
displayed instead of value if external compensation is turned off
OFF
Displays the value of the Phase Selection Input in mA (mA i/p channel 1)
displayed instead of value if phase selection set to 'Internal'
OFF
Value of the external input in the selected parameter and unit
(DEWP, TEMPR, PRESS, OTHER or NONE)
displayed instead of value if external compensation parameter is set
OFF
to
NONE
Table 3
50.0
28
OFF
OFF
Secondary parameters page
Secondary parameters
OPERATION
