2.7.10 Field Cal Page

In the HCG version, the calibration parameters shown in table 13 will be for the currently
selected phase.
Parameter
CAL TYPE
REF GAS 1
ACTUAL 1
REF GAS 2
ACTUAL 2
Adjusted% ~
See Section 3 for field calibration procedure.
24
Description/Operation
Current Time
Table 12 Clock page parameters
CAL TYPE
REF GAS 1
ACTUAL 1
REF GAS 2
ACTUAL 2
Adjusted% ~
Figure 28
Description/Operation
1 POINT or 2 POINT
Cal reference gas for 1 point cal, lower cal reference gas for 2 point cal
Actual measured TG for REF GAS 1
See Section 3.1
Upper cal reference gas for 2 point cal
Disabled if 1 point cal selected
Actual measured TG for REF GAS 2
See Section 3.2
Disabled if 1 point cal selected
TG% reading before then after calibration
Table 13 Field Cal parameters
XTC601 User's Manual
Hours
Minutes
Day
Month
Year
1/2 POINT
0.00-100.00
0.00-100.00
0.00-100.00
0.00-100.00
0.00-100.00
Field Cal page
97400 Issue 3.1, January 2017
Options
00-23
00-59
1-31
1-12
00-99
**:**:**
