OPERATION
2.5.4

Target Gas Min/Max Page

This indicates the minimum and maximum Target Gas values measured, along with date/
time of occurrence. The value is reset manually via the Reset Page in the User Menu.
This data is not saved in NV memory and is not available via serial communications or
in the blind unit.
NOTE: In the HCG version, the value is reset each time the phase is changed.
2.5.5

Alarms Log Pages

A maximum of 40 High/Low alarms, along with date and time of occurrence, are
recorded in a ring buffer in NV memory. The most recent alarm will overwrite the oldest
alarm when more than 40 alarms are recorded. The data is displayed over a maximum
of 10 pages (with 4 alarms on each page). The latest alarm record is displayed in line
1 of page 1. This data is not available via serial communications or in the blind unit.
The data is reset manually via the Reset Page in the User Menu. The data is saved and
restored when the instrument is restarted.
14
MINIMUM 0.00
D12/01 T 19:29:44
MAXIMUM 0.00
D12/01 T
Target gas min/max page
Figure 14
ALARM DATE
LOW 02/01
HIGH 02/01
LOW 02/01
HIGH 02/01
Figure 15 Alarms log page
XTC601 User's Manual
%CO2
%CO2
19:29:44
TIME P1
12:50:40
11:10:32
11:00:29
10:20:00
