APPENDIX E
67 Alarm Configuration
68 Bridge Pot Wiper Code
69 Gain Pot Wiper Code
70 mAINPUT1 4 mA Cal point
71 mAINPUT1 20 mA Cal point
72 mAINPUT2 4 mA Cal point
73 mAINPUT2 20 mA Cal point
74 mAOUTPUT1 4 mA Cal point
75 mAOUTPUT1 20 mA Cal point
76 mAOUTPUT2 4 mA Cal point
77 mAOUTPUT2 20 mA Cal point
78 Last Cal Date DATE/MONTH
Last Cal Date: Field or Factory
79
(bit 15) / YEAR (bits0-3)
80 Hours of Operation
Restore Factory Settings / Cal
81
data (write 5491 to this reg)
82 Set Clock HRS
83 Set Clock MIN
84 Set Clock DAY
85 Set Clock MONTH
86 Set Clock YEAR
87 % Reading of Gas
88 Cell Temperature
89 PCB temperature (from MSP)
mA1 Input in % (phase indicator
90
signal)
91 mA2 Input (ext sensor signal)
92 Status Flags register
93 Clock HOURS/MIN
94 Clock SEC/DAY
95 Clock MONTH/YEAR
96 % MINIMUM (stats)
97 % MAXIMUM (stats)
98 VCOMP
99 Firmware Version
100 Live ADC
101 Live ADC mAINPUT1
102 Live ADC mAINPUT2
103 Live ADC Cell Tempr
104 Live ADC PCB Tempr
105 % without field cal correction
58
R/W See Reg Details
R 0-1023
R 0-1023
R 0-8191
R 0-8191
R 0-8191
R 0-8191
R 0-8191
R 0-8191
R 0-8191
R 0-8191
R 1-31/1-12
0=Factory, 1=Field
R
/ 0-99
R 0-65535
W 5491
W 00-23
W 00-59
W 01-31
W 01-12
W 00-99
R -199.00-199.99%
-99.9-99.9 or
R
equivalent in F or K
-99 to 99°C or
R
equivalent in F or K
R 0.0-100.0%
R See Reg Details
R 0-65535
R 00-23 / 00-59
R 00-59 / 01-31
R 0-12 / 00-99
R -199.00-199.99%
R -199.00-199.99%
R 0-8191
R 0.00-200.00
R 0-8191
R 0-8191
R 0-8191
R 0-8191
R 0-8191
R -199.00-199.99%
97400 Issue 3.1, January 2017
XTC601 User's Manual
L ALARM_TYPES
A BRIDGE_WIPER
A GAIN_WIPER
A MA_IN1_LOADC
A MA_IN1_HIADC
A MA_IN2_LOADC
A MA_IN2_HIADC
A MA_OUT1_LODAC
A MA_OUT1_HIDAC
A MA_OUT2_LODAC
A MA_OUT2HIDAC
J CAL_DATE_DDMM
J CAL_DATE_YY
A HOURS_USED
A SET_FACTORY
J SET_RTC_HRS
J SET_RTC_MIN
J SET_RTC_DAY
J SET_RTC_MONTH
J SET_RTC_YEAR
G GAS_READING
F CELL_TEMPR
K INT_TEMPR
F MA_IN1_PERC
F MA_IN2_VAL
I STATUS_REG
J RTC_HRS_MIN
J RTC_SEC_DAY
J RTC_MONTH_YEAR
G RM_XTCSTAT_MIN
G RM_XTCSTAT_MAX
A VCOMP_ADC
G FIRM_VER
A XTC_ADC
A MA1IN_ADC
A MA2IN_ADC
A CELLT_ADC
A INT_T_ADC
G XTC_NO_FIELDCAL
