Example of "Weekday metering"
Tab. 17: Program as program lines / instructions
No. Time event
01 workdays 1 (Mo-
Fr)
02 workdays 1 (Mo-
Fr)
03 workdays 1 (Mo-
Fr)
04 workdays 1 (Mo-
Fr)
05 workdays 1 (Mo-
Fr)
06 workdays 1 (Mo-
Fr)
How to enter the program lines / instruc‐
tions:
Task:
The pump is to meter 2 litres every half hour every weekday (Mon-Fri)
between 8:00 and 11:00:
Solution:
As you define switching times with the timer, you need to first define the
switching points at 08:30, 09:30 and 10:30.
To meter 2 litres, the pump needs to work in
for 10 min at a 'Capacity' of 12,000 l/h. A 'Capacity' of 12,000 l/h is
thereby added to the switching points.
You also need to define the switching times to stop the pump at 08:40,
09:40 and 10:40 - paired with the
Action
Switching time
08:30 Manual
08:40 Stop
09:30 Manual
09:40 Stop
10:30 Manual
10:40 Stop
1. To program the timer, set
Activation' to 'inactive' .
è
ð The first line of the timer menu
'Inactive' .
2. Always enter the program / instructions from the table, above, into
the newly created instruction under
...' (Do not get irritated: the timer program automatically sorts
è
the instructions).
3. To activate the timer, set
ð The first line of the timer menu
'active' .
The timer starts working - the timer identifier
continuous display.
4. Test your programming!
The secondary display "Timer" can help here, which shows the
next instruction and the remaining time. (To access this secondary
display, press the
series of small circles appears below - immediately turn the
[Clickwheel] to navigate to the last circle and press the
[Clickwheel] .)
The continuous display itself shows information on the current
status of the pump in the dark bar.
'Manual' 'operating mode'
'Halt' action.
Capacity
12,000 l/h
-
12,000 l/h
-
12,000 l/h
-
'Menu / Information è Timer
'Timer status' then shows
'Timer è Set timer è new
'Activation' to 'active' .
'Timer status' then displays
[Clickwheel] in a continuous display until a long
'Menu'
Set up /
Comment
Meter at 12,000
l/h
Stop
Meter at 12,000
l/h
Stop
Meter at 12,000
l/h
Stop
is visible in the
