'Menu'
Set up /
12.4.2.1 Reprogram program line (
12.4.2.1.1 Principle design of a program line
Example
Time event (trigger)
workdays 1 (Mo-Fr)
62
'new' )
In principle, an (imaginary) program line / instruction is set up as follows:
Time event (trigger)
workdays 1
(Mo-Fr)
This corresponds to the following instruction:
WHEN triggering event, THEN action
The time event (trigger) defines what action or at what time an action is to
take place.
The action defines which type of action is to take place.
The finished program line/ instruction looks like this:
Action
Time of day 12:00 Manual
The example means:
When it is 12:00 on a workday, then the pump is to work in
mode at 20.00 l/h.
Using Config I/Os
If you wish to use Config I/Os as inputs or outputs, you
first need to configure them as a 'Timer input' or 'Timer
output' under 'Menu / Information è Settings
Config I/Os è ...'.
è
CAUTION!
'Timer status' is set to 'active' , the pump can nei‐
If the
ther be set nor programmed!
'Timer status' under 'Activation' to
To do so, set the
'inactive' .
Action
Time of day Manual
12:00
Instruction 03/05
workdays 1 (Mo-Fr)
12:00
Manual
20.00 l/h
20.00 l/h
20.00 l/h
'Manual'
B1106
