14. Instructions for installing optional accessories

1. Press in frame

2. Converting from pushbutton to foot switch

Connecting foot switch for a machine
with horizontal drilling unit
1. Press in frame
WARNING
Risk of injury
Servicing and maintenance work must only be carried out
by instructed, qualified personnel.
Before attempting any servicing and maintenance work
or installing the optional accessories, switch the machine
off, disconnect the compressed air supply and implement
measures to prevent the machine from being switched
back on again without authorisation.
1
2. Converting from pushbutton to foot switch
The conversion set contains the foot switch, including two
connecting hoses. The foot switch must be placed on the floor
where it must not be allowed to slip.
82
82
3. Installing laser
82
4. Installing continuation stop
83
5. Installing support block
Tightening the screw on
the left / right regulates
the frame swivelling
ability.
Precision adjustment of continuation stops
i
2
Screw for adjusting
perpendicularity of
the press in frame.
Fig. 84: Fitting press in frame
Fig. 85: Foot switch
84
85
86
86
