Interchangeable drilling unit
1105 Pinion Z21
1106 Pinion Z32
1134 Auxiliary spindle, quick release chuck
1135 Main spindle, quick change chuck
1151 Deep groove ball bearing
1184 Deep groove ball bearing
1193 Special pinion Z25
1553 Feather key
2020 Drilling unit block, 6 spindle unit
2021 Drilling unit cover, 6 spindle unit
2022 Clamp pin
2023 Drill bit guard, 6 spindle unit
2024 Seal, 6 spindle unit
2025 Wire spring 6/9R
2026 Dummy spindle
2027 Bowex Junior coupler, size 19
2028 Cable grommet
2029 Clamping lever, rigid
2069 Drilling unit block 9R
2070 Drilling unit cover 9R
2071 Seal 9R
2072 Drill bit guard 9R/9W
2073 Drilling block, 9W
2074 Drilling unit cover, 9W
2075 Seal, 9W
2076 Wire spring, 9W
2092 Special main spindle
2093 Customised auxiliary spindle
