Hettich BlueMax Mini Modular Plus Operating Manual page 20

Technical information
Digital display
Fig. 8: Position display panel
Operating mode:
Reference
value
Chain
dimension
Offset
dimension
Inch display
20 20 20
Press simultaneously
Switch over incremental
- absolute
This button activates the
selectable offset dimen-
sions
Switch over to inch
mode, fraction notation
(1/64, 1/32, 1/16), deci-
mal 0.001
Parameter level:
Activate
parameter
level
Select
parameter
Select
decades
Increase
decade
Change
sign
Leave para-
meter level
Press for approx. 3
seconds
Press button once
Press button once
Press button once
Press button once
Press for approx. 3
seconds
