1. Preparing machine
Connecting to extractor system
Drilling hole line, interchangeable drilling unit,
9 spindles
38
1. Preparing machine
The BlueMax Mini Modular Plus is shipped in cardboard
packaging. A number of parts and components must be installed
38
to make the machine ready for operation. Once assembled, the
machine must be thoroughly cleaned (removal of dust and any
38
oil or grease)
38
Before switching the automatic drilling and insertion machine
39
on, satisfy yourself that
39
• any installation, set up and servicing work has been
40
• no persons are present in the danger zone, let alone
40
working on it
41
42
42
• Make sure the machine is safe and in proper working order
42
• Make sure the machine has been set up for the relevant
43
product
43
44
Readiness for use
44
44
45
45
46
46
47
• The machine is firmly mounted on a bench / base frame
48
48
48
Connecting to extractor system
49
Connect the machine to an extractor system. It is compulsory
to use flexible, fire-retardant hose for connection to an
49
extractor system.
Fit the extractor system's extraction hose to suction
connector
and secure this in place with a hose clamp.
1
The extractor system must have an airflow rate of at least 20 m/s.
Extraction hose diameter: Ø 80 mm. Route extraction hose so as
not to exert strain on the suction connector!
Fig. 22: Suction extraction connector
1
