Drilling hole line, interchangeable drilling unit, 9 spindles

On the control unit, set selector switch to the "Drill" position.
• Move panel up against upright centre stop
1
• Hold down foot switch (pushbutton) until drilling process
has been completed. You can now see the first hole line
• Fold down centre stop and move panel to the right until
2
it meets marking pin
6
• Push marking pin into second hole
foot switch (pushbutton)
NOTE
Keep moving the panel towards the middle of machine
when the continuation stop dips into drill hole.
• Perform the second work step. Depending on panel length,
this work step may have to be repeated.
• Hold-down clamp only holds panel in place while holes
8
are being drilled.
• Afterwards, clean the bench to provide an even and clean
support surface for the next panel.
8
Fig. 28: Hole line
Fig. 30: Centre stop
