Hettich BlueMax Mini Modular Plus Operating Manual page 21

Parameter Specification
System configuration:
P01: A A = 0: positive counting direction
A = 1: negative counting direction
Display mode:
A = 0: mm display symbol " mm "
A = 1: inch display symbol " Inch "
P02: A
A = 2: mm display symbol " m "
A = 3: mm display symbol " ° "
A = 4: mm display no symbol
P03: A Decimal point (0...4)
Standby:
0: Sleep mode deactivated (not recommen-
P04: A ded)
Auto power ON when sensor moving or
button press (button F)
Button lock:
A: " SET "
P05: ABC B: " Incr/Abs " (0 = not active) -
C: " * "
Basic resolution:
P07: A A = 0: resolution 0.01 mm
A = 1: resolution 0.1 mm
P08: Multiplication factor (0.0001...9.9999)
P09: Reference value (-999999.9... + 999999.9)
P10: Offset dimension 1 (-999999.9... + 999999.9)
P11: Offset dimension 2 (-999999.9... + 999999.9)
P12: Offset dimension 3 (-999999.9... + 999999.9)
Configuration of offset dimensions (0...3)
A = 0: offset dimensions cannot be
selected
A = 1: offset dimension 1 can be selected
P13: A
A = 2: offset dimensions 1 and 2 can be
selected
A = 3: offset dimensions 1 and 2 and 3
can be selected
P9: Software version
Calibration:
The sensor must be on the magnetic strip!
> Switch off device
–> Switch device back on again by simultaneously pressing
button
–> This triggers the sensor calibration and displays "Cal 0".
Slowly move sensor in one direction on the magnetic strip.
On completion of calibration (display "Cal 0" ... "Cal 4") the
display returns to the normal status
Default
0
0
2
01
(0 = not active) -
(1 = active)
000
(1 = active)
(0 = not active) -
(1 = active)
0
1.0000
0.0
0.0
0.0
0.0
3
X.XX
