System Manual
MobileLAN
access
™
21XX

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MobileLAN 21 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Intermec MobileLAN 21 Series

Summary of Contents for Intermec MobileLAN 21 Series

  • Page 1 System Manual MobileLAN access ™ 21XX...
  • Page 2 The information contained herein is proprietary and is provided solely for the purpose of allowing customers to operate and/or service Intermec manufactured equipment and is not to be released, reproduced, or used for any other purpose without written permission of Intermec.
  • Page 3 Manual Change Record This page records the changes to this manual. The manual was originally released as version 001. Version Date Description of Change 11/1998 Added information about the 900 MHz UAP and WAP, and the OpenAir WAP. 6/1999 Added information about the IEEE 802.11 Direct Sequence radio and firmware upgrade features.

  • Page 5: Table Of Contents

    Contents Contents Before You Begin xiii Warranty Information xiii Safety Summary xiii Cautions and Notes xiv About This Manual xiv Patent Information xv Other Related Manuals xv Getting Started Overview of the MobileLAN access 21XX Family 1-3 Features 1-4 What’s New for Release 1.7X? 1-5 Understanding the LEDs 1-6 Understanding the Ports 1-8 How the 21XX Fits in Your Network 1-11...
  • Page 6 MobileLAN access 21XX System Manual Connecting to Your Wired LAN 2-8 Connecting to Power 2-8 Installing the 2100 2-9 Mounting the 2100 2-9 Attaching an Antenna 2-9 Connecting to Your Wired LAN 2-9 Connecting to Power 2-10 Installing the 2102/2106 2-10 Mounting the 2102/2106 Using the Mounting Bracket 2-11 Positioning the Standard Antenna 2-12 Attaching an External Antenna (2102) 2-12...
  • Page 7 Contents Using Predefined Subtype Filters 3-17 Customizing Subtype Filters 3-18 Configuring Advanced Filters 3-20 Setting Filter Values 3-20 Setting Filter Expressions 3-21 Ethernet Advanced Filter Example 3-23 Configuring the Spanning Tree Configuring the Spanning Tree Parameters 4-3 About the Root Access Point 4-5 About Bridging 4-6 About Secondary LANs and Designated Bridges 4-8 Configuring Global Parameters 4-9...
  • Page 8 MobileLAN access 21XX System Manual Configuring the Radios About the Radios 5-3 Configuring the IEEE 802.11b Radio 5-4 Configuring 802.11b Radio Advanced Parameters 5-7 Configuring a MobileLAN voice Network 5-9 Configuring the IEEE 802.11a Radio 5-10 Configuring 802.11a Radio Advanced Parameters 5-13 Configuring the WLI Forum OpenAir Radio 5-15 Setting Manual MAC Parameters 5-17 Configuring the 902 MHz Radio 5-20...
  • Page 9 Contents Managing, Troubleshooting, and Upgrading the 21XX Managing the 21XX 7-3 Using Simple Network Management Protocol (SNMP) 7-3 Using Intermec Device Registration Service (IDRS) Servers 7-5 Maintaining the 21XX 7-6 Understanding the LEDs Lighting Sequence 7-6 Viewing AP Connections 7-7...
  • Page 10 MobileLAN access 21XX System Manual Using Command Console Mode 8-11 Entering Command Console Mode 8-11 Using the Commands 8-12 Using TFTP Commands 8-14 Using sdvars Commands 8-18 Creating Script Files 8-21 Specifications and Default Settings Specifications A-3 2101 A-3 2100 A-4 2102 A-5 2106 A-6 Radio Specifications A-7...
  • Page 11 Contents 902 MHz Radio Configuration Menu Defaults A-22 S-UHF Radio Configuration Menu Defaults A-22 Glossary Index...
  • Page 12 asdfasdf...

  • Page 13: Before You Begin

    To receive a copy of the standard warranty provision for this product, contact your local Intermec sales organization. In the U.S.A. you can call 1-800-755-5505, and in Canada call 1-800-668-7043. Otherwise, refer to the Worldwide Sales & Service list that ships with this manual for the address and telephone number of your Intermec Technologies sales organization.

  • Page 14: Cautions And Notes

    The MobileLAN access 21XX System Manual provides you with information about the features of the access points, and how to install, configure, and troubleshoot it. You must be familiar with your host PC, your network, your other Intermec equipment, and your data collection network.

  • Page 15: Patent Information

    Other Related Manuals You may need additional information when working with the MobileLAN access 21XX products. Please visit our Web site at www.intermec.com to download many of our current manuals in PDF format. To order printed versions of the Intermec manuals,...
  • Page 16 sadsf...

  • Page 17: Getting Started

    Getting Started...
  • Page 18 MobileLAN access 21XX User’s Manual...

  • Page 19: Overview Of The Mobilelan Access 21Xx Family

    Overview of the MobileLAN access 21XX Family Intermec’s MobileLANaccess 21XX family of access points delivers reliable and seamless wireless performance to almost any operational environment. They are designed for standards-based connectivity and they support industry standard IEEE 802.11b, WLI Forum OpenAir, and IEEE 802.11a wireless technologies.

  • Page 20: Features

    MobileLAN access 21XX System Manual Features This table summarizes the similarities and differences between the access points. 21XX Feature Comparison Feature 2101 2100 2102 2106 Access Point Point-to-Point Bridge Not Yet (Wireless Bridge) Wireless Access Point (Repeater) Radios 802.11b, OpenAir 802.11b, OpenAir, 802.11b, OpenAir 802.11a...

  • Page 21: What's New For Release 1.7X

    Getting Started Other features of the access points include the • ability to be managed by MobileLAN manager. • ability to be managed using a Web browser, Telnet, and SNMP. • ability to be a DHCP server or client. • ability to upgrade over the network or serial port.

  • Page 22: Understanding The Leds

    MobileLAN access 21XX System Manual Understanding the LEDs The 2102 and 2106 have four LEDs; the 2101 and 2100 have five LEDs. The 2101 and 2100 have a separate LED for each of the radios. Description Power Remains on when power is applied. Wireless #1 or Flashes when a frame is transmitted or received on the radio port for Radio...
  • Page 23 Getting Started 2100 LEDs Wireless Wireless Root/ Power Wired LAN error 21XXT003.eps 2102 and 2106 LEDs Wired Radio Power Root/error 21XXT031.eps...

  • Page 24: Understanding The Ports

    MobileLAN access 21XX System Manual Understanding the Ports Caution You must use the appropriate Intermec power supply with these devices or equipment damage may occur. Conseil Vous devez utiliser la source d'alimentation Intermec adéquate avec cet appareil sinon vous risquez d'endommager l'équipement.
  • Page 25 Getting Started 2100 Ports Without Fiber Optic Option Cable access door Power Serial port 21XXT007.eps port 10BaseT/ 100BaseTx Ethernet port 2100 Ports With Fiber Optic Option Cable access door Power Serial port 21XXT002.eps port Fiber 10BaseT/ optic port 100BaseTx Ethernet port...
  • Page 26 MobileLAN access 21XX System Manual 2101 Ports Without and With Fiber Optic Option Power port Power port Fiber optic 10BaseT/100BaseTx port 21XXT026.eps 10BaseT/100BaseTx Ethernet port 21XXT036.eps Ethernet port Serial port Serial port 2102 Ports Power 10BaseT Serial port Ethernet port port 21XXT030.eps 2106 Ports...

  • Page 27: How The 21Xx Fits In Your Network

    Getting Started How the 21XX Fits in Your Network In general, the 21XX forwards data from wireless end devices to the wired Ethernet network. You can also use the access point as a point-to-point bridge or as a WAP. Use the access point in the following locations and environments.

  • Page 28: Using Access Points And Roaming End Devices

    MobileLAN access 21XX System Manual Using Access Points and Roaming End Devices For larger or more complex environments, you can install multiple access points so that wireless end devices can roam from one access point to another. In large installations, these access points may be on different subnets.

  • Page 29: Using Access Points With Dual Radios For Redundancy

    Getting Started Using Access Points with Dual Radios For Redundancy You can use the multiple 2101s and 2100s that have two 802.11b radios or two OpenAir radios to provide redundancy for your network. In each access point, you need to configure one radio’s node type as a Master, which communicates with the wireless end devices and configure the other radio’s node type as a Station.

  • Page 30: Using Access Points To Create A Point-To-Point Bridge

    MobileLAN access 21XX System Manual Using Access Points to Create a Point-to-Point Bridge You can use access points to create a point-to-point bridge between two wired LANs. You can have one access point wired to a network in one building and have a second access point wired to a network in another building.

  • Page 31: Using An Access Point As A Wap

    Getting Started Using an Access Point as a WAP You can extend the range of your network by configuring the access point as a wireless access point (WAP). You position the WAP in a strategic location so it receives data from wireless end devices and then forwards the data toward the wired network.

  • Page 32: Configuring The 21Xx (Setting The Ip Address)

    Ethernet segment and subnet as the access point. Or, it can also be installed on a PC with a wireless link (configured to Intermec’s default settings) to the access point. For help, see “Using the MobileLAN access Utility” in the next section.
  • Page 33 Note: You need to install the MobileLAN access Utility on a PC that is on the same IP subnet as the access point. Or, you need to install it on a PC with a wireless link (configured to Intermec’s default radio settings) to the access point. Before you use the utility, you must have an active radio connection.

  • Page 34: Using A Communications Program

    • an RS-232 null-modem cable. One end of this cable must be a 9-pin socket connector to connect to the serial port on the access point. Intermec offers a 9- socket to 9-socket null-modem cable (Part No. 059167). •...
  • Page 35 4. Press Enter when the message “Starting system” appears on your PC screen. The Username field appears. 5. Type the default username Intermec, press Enter, type the default password Intermec, and press Enter. The Access Point Configuration menu appears. 1-19...
  • Page 36 MobileLAN access 21XX System Manual 6. If you are not using a DHCP server, you need to manually assign an IP address. Configure these parameters in the TCP/IP Settings menu: IP Address A unique IP address. IP Subnet Mask The subnet mask that matches the other devices in your network.

  • Page 37: Using A Web Browser Interface

    All OpenAir radios must have the same security ID to communicate. Note: Intermec recommends that you set the security ID to a value other than NULL (the default value) to prevent unauthorized access to your network. 900 MHz radios If you are using 900 MHz radios, configure the Mode-Channel parameter.
  • Page 38 MobileLAN access 21XX System Manual To use a Web browser interface 1. Determine the IP address of the access point. If a DHCP server assigned the IP address, you must get the IP address from the DHCP server. 2. Start the Web browser application. 3.

  • Page 39: Saving Configuration Changes

    Getting Started 4. Click Login. The TCP/IP Settings screen appears. You can define a user name and password. For help, see “Setting Up Logins” in Chapter 6. Your Web browser session is established. Note: Although you can use several different methods to manage the access point remotely, this manual assumes you are using a Web browser.
  • Page 40 MobileLAN access 21XX System Manual To save your changes 1. On the menu bar, click Save/Discard Changes. This screen appears and is explained next. Click to use your new configuration now. Click to use your new configuration the next time you reboot the access point.

  • Page 41: Installing The 21Xx

    Installing the 21XX...
  • Page 42 21XX Access Point Technical Reference Manual...

  • Page 43: Installation Guidelines

    Installation Guidelines Intermec recommends that you have Intermec or other certified providers conduct a site survey to determine the ideal locations for all of your network components. A proper site survey requires special equipment and training. The following general practices should be followed in any installation: •...

  • Page 44: Cordless Telephones

    Locking bracket kit (Part No. 070184) • Dual antenna bracket kit (Part No. 069888) • Power supply holder kit (Part No. 069893) To order one of these kits, contact your Intermec representative. To mount the 2101, follow the instructions in the kit.

  • Page 45: Attaching The Standard Antenna

    These steps are explained in detail in the next sections. When you are done, you need to configure the 2101 so it can communicate with your network. Attaching the Standard Antenna Intermec offers a variety of antennas and antenna accessories. For more information, see “Antennas and Antenna Accessories” in Appendix A. To attach the standard antenna 1.

  • Page 46: Attaching The Dual Antenna Bracket For Antenna Diversity (802.11B)

    MobileLAN access 21XX System Manual Attaching the Dual Antenna Bracket for Antenna Diversity (802.11b) The 802.11b radio features antenna diversity, Antenna which lets you attach two antennas to a single radio. One antenna port sends and receives data, while the other antenna port only receives data.
  • Page 47 Installing the 21XX Mounting the 2101 Using the Wall Bracket (continued) Brass inserts Mounting screws (4 places) 2101G004.eps 2. Use the mounting bracket as a template to mark the location of the mounting holes on the mounting surface. 3. Drill the mounting holes. 4.

  • Page 48: Connecting To Your Wired Lan

    You can either use a power cord to connect the 2101 directly to an AC power outlet or you can use the MobileLAN splitter to connect Ethernet and power to a MobileLAN power bridge and the Intermec Power Hub. For help, see “Using the MobileLAN splitter” later in this chapter.

  • Page 49: Installing The 2100

    These steps are explained in detail in the next sections. When you are done, you need to configure the 2100 so it can communicate with your network. Mounting the 2100 If you want to mount the 2100 to a wall or beam using an Intermec mounting bracket kit, you need one of these mounting kits: •...

  • Page 50: Connecting To Power

    2100 with the power over Ethernet option. This option lets you power the 2100 through its Ethernet cable that is connected to a MobileLAN power bridge and the Intermec Power Hub. For help, see the documentation that shipped with your MobileLAN power bridge.

  • Page 51: Mounting The 2102/2106 Using The Mounting Bracket

    Installing the 21XX Mounting the 2102/2106 Using the Mounting Bracket If you want to mount the 2102 or the 2106 on a wall, it ships with a mounting bracket and four mounting screws. Install the 2102 or the 2106 in this mounting bracket on a sturdy surface in accordance with local building codes.

  • Page 52: Positioning The Standard Antenna

    To attach an external antenna to the 2102, you must first disconnect the built-in antenna and then attach an antenna cable directly to the radio card. Intermec offers a variety of antennas and antenna accessories, including diversity antennas. For more information, see “Antennas and Antenna Accessories”...
  • Page 53 Installing the 21XX Attaching an External Antenna (continued) Door Antenna wire 21XXT010.eps 3. Tuck the antenna wire inside the 2102 housing. 4. Remove the punch-out tab from the door. Door Punch-out Pliers 21XXT009.eps 5. Attach the antenna cable to the radio by inserting the cable connector into the radio card.

  • Page 54: Connecting To Your Ethernet Network

    You can either use a power cord to connect the 2102 or 2106 directly to an AC power outlet or you can use the MobileLAN splitter to connect Ethernet and power to a MobileLAN power bridge and the Intermec Power Hub. For help, see “Using the MobileLAN splitter” later in this chapter.

  • Page 55: Connecting To Your Fiber Optic Network

    • a square connector (SC) network. • a straight tip (ST) network. For help choosing the proper cord and adapter, contact your local Intermec representative Note: All cables must be multimode, 62.5/125 µm. Connecting to an MT-RJ Network To connect to an MT-RJ network, you need •...

  • Page 56: Connecting To An Sc Network

    MobileLAN access 21XX System Manual Connecting to an SC Network To connect to an SC network, you need • a patch cord for connecting the MT-RJ transceiver to the SC adapter. • an adapter for connecting an SC cord to an SC network. To connect to an SC network 1.

  • Page 57: Connecting To An St Network

    Installing the 21XX Connecting to an ST Network To connect to an ST network, you need • a patch cord for connecting the MT-RJ transceiver to the ST adapter. • an adapter for connecting an ST cord to an ST network. To connect to an ST network 1.
  • Page 58 The data passes through the splitter and then through the Ethernet connector, which is connected to the access point 10BaseT/100BaseTx port. You order the MobileLAN splitter as an accessory. Intermec offers two different splitters, depending on your access point input voltage. •...

  • Page 59: External Antenna Placement Guidelines

    The antenna ports on the radio card are marked | and ||. Port | is the send/receive port; port || is the receive only port. Intermec recommends that you use two antennas for optimal performance of your 802.11b radio. If you attach only one antenna to this radio, you must attach it to Port |.

  • Page 60: Positioning Antennas For Antenna Diversity

    MobileLAN access 21XX System Manual Positioning Antennas for Antenna Diversity The 802.11b radio features antenna diversity, which means that two antennas can be attached to a single radio. If you are using two antennas for one 802.11b radio, placement of the antennas is critical because each antenna has a particular function. Antennas placed too close together may cause interference with each other.

  • Page 61: Positioning Antennas For An Openair Wap

    Positioning Antennas for an OpenAir WAP If the OpenAir WAP has two radios, you need to use external antennas and position them at the recommended distances for proper functioning. There are two types of Intermec-recommended antennas you can use: • Omni •...
  • Page 62 MobileLAN access 21XX User’s Manual...

  • Page 63: Configuring The Ethernet Network

    Configuring the Ethernet Network...
  • Page 64 MobileLAN access 21XX User’s Manual...

  • Page 65: Configuring The Tcp/Ip Settings

    Configuring the Ethernet Network This chapter explains how to configure the 21XX so that it communicates with your Ethernet network. Configuring the TCP/IP Settings If you are using a DHCP server to automatically assign an IP address to the access point, go to “Configuring the 21XX as a DHCP Client”...
  • Page 66 MobileLAN access 21XX System Manual 6. If you want to configure the access point as a DHCP server, see “Configuring the 21XX as a DHCP Server” later in this section. 7. Click Submit Changes to save your changes. To activate your changes, from the menu bar click Save/Discard Changes and then click Save Changes and Reboot.

  • Page 67: Configuring The 21Xx As A Dhcp Client

    Configuring the Ethernet Network Configuring the 21XX as a DHCP Client You can use a DHCP server to automatically assign an IP address to your access point; that is, the access point can act as a DHCP client. Note: You cannot configure the access point as both a DHCP server and a DHCP client. To configure the 21XX as a DHCP client 1.

  • Page 68: Configuring The 21Xx As A Dhcp Server

    MobileLAN access 21XX System Manual Configuring the 21XX as a DHCP Server You can configure the access point as a simple DHCP server that can provide DHCP server functions for small installations where no other DHCP server is available. The DHCP server will offer IP addresses to any DHCP client it hears as long as a pool of unallocated IP addresses is available.
  • Page 69 Configuring the Ethernet Network 3. Click the down arrow on the right side of the DHCP Mode field and choose “This AP is a DHCP Server.” 4. Click Submit Changes to save your changes. 5. Click DHCP Server Setup. The DHCP Server Setup screen appears. 6.

  • Page 70: Supported Dhcp Server Options

    MobileLAN access 21XX System Manual DHCP Server Parameters Table (continued) Parameter Explanation DNS Address 2 The IP address of a Domain Name Server that will be distributed to DHCP clients. You can enter up to two DNS addresses to be delivered to DHCP clients.

  • Page 71: Configuring The 21Xx As An Arp Server

    Configuring the Ethernet Network NAT operation is disabled or enabled automatically depending on the continuous range of addresses you enter into the DHCP server. NAT is disabled if the range of addresses to be given to DHCP clients is on the same subnet as the access point. NAT is enabled if the range of addresses to be given to DHCP clients is not on the same subnet as the access point;...

  • Page 72: Configuring The 21Xx To Send Arp Requests

    MobileLAN access 21XX System Manual To configure the 21XX as an ARP server 1. From the menu, click TCP/IP Settings. The TCP/IP Settings screen appears. 2. Click the down arrow on the right side of the ARP Server Mode field and choose No Flooding or Normal Flooding.

  • Page 73: Configuring The Ethernet Or Fiber Optic Settings

    Configuring the Ethernet Network Configuring the Ethernet or Fiber Optic Settings Many of the standard Ethernet or fiber optic settings are configured in the TCP/IP Settings screen. For help, see “Configuring the TCP/IP Settings” earlier in this chapter. In the Ethernet Settings screen, you can •...
  • Page 74 MobileLAN access 21XX System Manual To configure the Ethernet or fiber optic settings 1. From the menu, click Ethernet. The Ethernet screen appears. 2. If you have a fiber optic port, click the down arrow on the right side of the Port Type field and choose which port is connected to the Ethernet network.

  • Page 75: Configuring Ethernet Filters

    Configuring the Ethernet Network Configuring Ethernet Filters You can set both Ethernet and IP tunnel filters, and you can create protocol filters for both predefined and user-defined protocol types. In addition, you can define arbitrary frame filters based on frame content. For help configuring IP filters, see “Configuring IP Tunnel Filters”...

  • Page 76: Using Ethernet Frame Type Filters

    MobileLAN access 21XX System Manual 3. Enter up to 20 MAC addresses. MAC addresses consist of six hex pairs that are separated by spaces, colons, or hyphens. 4. Click Submit Changes to save your changes. To activate your changes, from the menu bar click Save/Discard Changes and then click Save Changes and Reboot.
  • Page 77 Configuring the Ethernet Network Frame Type Filters Screen 2. In each frame type field, click the down arrow on the right side of the Action field and set the action to Pass or Drop. In each frame type field, click the down arrow on the right side of the Scope field and set the scope to Unlisted or All.
  • Page 78 MobileLAN access 21XX System Manual The following table explains various frame types. Frame Type Explanation DIX IP TCP Ports Primary Internet Protocol Suite (IP) transport protocols. DIX IP UDP Ports SNAP IP TCP Ports SNAP IP UDP Ports DIX IP Other Protocols IP protocols other than TCP or User Datagram Protocol (UDP).

  • Page 79: Using Predefined Subtype Filters

    Configuring the Ethernet Network Using Predefined Subtype Filters You can configure the access point to pass or drop certain predefined frame subtypes. To configure predefined subtype filters 1. From the main menu, click Ethernet and then click Predefined Subtype Filters. The Predefined Subtype Filters screen appears.

  • Page 80: Customizing Subtype Filters

    MobileLAN access 21XX System Manual Customizing Subtype Filters You can configure the access point to pass or drop certain customized frame subtypes. You define the action, subtype, and value parameters. Action Set the action to Pass or Drop. If you select Pass, then all frames of that subtype and value are passed.
  • Page 81 Configuring the Ethernet Network 5. Click Submit Changes to save your changes. To activate your changes, from the menu bar click Save/Discard Changes and then click Save Changes and Reboot. For help, see “Saving Configuration Changes” in Chapter 1. The following table describes frame subtype filters and their values. Subtype Value DIX-IP-TCP-Port...

  • Page 82: Configuring Advanced Filters

    You can use filter values and filter expressions to minimize network traffic over the wireless links; however, Intermec recommends that you use advanced Ethernet filters only if you have an extensive understanding of network frames and their contents. Use other existing filters whenever possible.

  • Page 83: Setting Filter Expressions

    Configuring the Ethernet Network Setting Filter Expressions You can set filter expressions by specifying parameters for packet filters. You can also create a filter expression, which is executed in ascending order based on the ExprSeq values until the access point determines whether to pass or drop the frame. To set filter expressions 1.
  • Page 84 MobileLAN access 21XX System Manual The next table explains each parameter. Parameter Explanation ExprSeq Chains expressions together for filtering. After you change the (Expression parameter, the statements are reordered and renumbered so the Sequence) Expression Sequence order is maintained. The range is from 0 to 255. This parameter works with the Action parameter;...

  • Page 85: Ethernet Advanced Filter Example

    Configuring the Ethernet Network Ethernet Advanced Filter Example This example shows how to use Ethernet Advanced Filters to discard all DIX IP multicast frames except those from selected Ethernet devices. Set the following filter values for this example. Three value entries have a value ID of 3 to demonstrate how to enter a list. All entries with the same value ID belong to the same list.
  • Page 86 MobileLAN access 21XX System Manual Set the first filter expression as shown below. The following table explains the values used in the first filter expression. Parameter Value Explanation ExprSeq This is the first expression. Offset The offset is zero. Look at the first byte of the destination address. Mask Only check the Ethernet multicast bit.
  • Page 87 Configuring the Ethernet Network Set the second filter expression as shown below. The following table explains the values used in the second filter expression. Parameter Value Explanation ExprSeq This is the second expression. Offset The data for this expression begins at an offset of 12 bytes from the beginning of the destination address.
  • Page 88 MobileLAN access 21XX System Manual Set the third filter expression as shown below. The following table explains the values used in the third filter expression. Parameter Value Explanation ExprSeq This is the third expression. Offset The data for this expression begins at an offset of 6 bytes from the beginning of the destination address.

  • Page 89: Configuring The Spanning Tree

    Configuring the Spanning Tree...
  • Page 90 MobileLAN access 21XX User’s Manual...

  • Page 91: Configuring The Spanning Tree Parameters

    Configuring the Spanning Tree This chapter explains how to configure the spanning tree parameters, global flooding parameters, and global RF parameters. It also explains how to configure IP tunnels and IP tunnel filters. Configuring the Spanning Tree Parameters Access points automatically configure themselves into a self-organized network using a spanning tree topology.
  • Page 92 MobileLAN access 21XX System Manual The following table explains each parameter Parameter Explanation AP Name Enter a unique name for this access point. The name can be from 1 to 16 characters. The default is the access point serial number. If you have an OpenAir master radio, only the first 11 characters are used.

  • Page 93: About The Root Access Point

    Configuring the Spanning Tree Spanning Tree Settings Table (continued) Parameter Explanation Secondary LAN Determines when and if the access point can become the designated Bridge Priority bridge in a secondary LAN. To become a designated bridge, the access point must have at least one radio configured as a Station node or be the endpoint of an IP tunnel.

  • Page 94: About Bridging

    MobileLAN access 21XX System Manual After the root access point is elected, it transmits hello messages on all enabled ports. The spanning tree forms as other access points receive hello messages and attach to the network on the optimal path to the root. A non-root access point also transmits hello messages after it is attached to the network.
  • Page 95 Configuring the Spanning Tree Bridging Layer Functions Table Function Explanation Network Access points automatically configure into a self-organized network using a spanning tree Organization topology. As devices are added to or removed from the network, the access points automatically reconfigure to maintain reliable operation. The spanning tree provides efficient, loop-free forwarding of frames through the network and allows rapid roaming of end devices.

  • Page 96: About Secondary Lans And Designated Bridges

    IP routers and other network components. Also, you should enable bridging if the root access point and the Intermec gateway that supports the Intermec NNL devices are on different IP subnets. You may also need to enable bridging if your wireless end devices use terminal emulation running the NNL protocol or if you use wireless end devices that are running both IP and NNL.

  • Page 97: Configuring Global Parameters

    Configuring the Spanning Tree If an access point has the highest bridge priority on the secondary LAN, but it is not in the radio coverage area of an access point on the primary LAN, it cannot become the designated bridge. In this case, an access point with a lower bridge priority that is in the radio coverage area or an access point on the primary LAN becomes the designated bridge.
  • Page 98 MobileLAN access 21XX System Manual To configure global flooding 1. From the main menu, click Spanning Tree Settings. The Spanning Tree Settings screen appears. 2. Click Global Flooding. The Global Flooding screen appears. 3. Configure the Global Flooding parameters. For help, see the next table. 4.
  • Page 99 Configuring the Spanning Tree The following table explains each parameter. Parameter Explanation Multicast Flood Determines the flooding structure for inbound multicast frames with Mode unknown destination addresses. Universal Allows any wireless end device to communicate with any other wireless end device. Hierarchical Allows wireless end devices to communicate with nodes on the primary LAN but not with other wireless end devices.

  • Page 100: Configuring Global Rf Parameters

    MobileLAN access 21XX System Manual Configuring Global RF Parameters Use global RF parameters to set various parameters on the access points. If you are configuring the root access point and you set the Set Globally parameter to Enabled, the value for that parameter is set globally for all access points and wireless end devices in the network.
  • Page 101 Configuring the Spanning Tree The following table explains each parameter. Parameter Explanation RFC1042/DIX Determines how the access point will handle the conversion of Conversion RFC1042/DIX frames that are received on its 802.11b ports. Enabled Causes frames received on an 802.11b port with a protocol type equal to a value in the “RFC1042 types to pass through”...

  • Page 102: About Ip Tunnels

    MobileLAN access 21XX System Manual About IP Tunnels The physical boundary of a wireless network is usually defined by the presence of an IP router. Multiple independent wireless networks may exist, each with its own LAN ID, root access point, and set of wireless end devices. In this environment, an end device can only operate within the limited coverage area of its own network and cannot roam across IP subnet boundaries.
  • Page 103 Configuring the Spanning Tree IP Tunnels Host Wireless stations UAP 1 UAP 2 (root) Primary LAN home subnet IP router IP network UAP 3 (Designated IP router Bridge) UAP 4 UAP 5 Secondary LAN remote subnet 21XXT028.eps Wireless stations A non-root access point can concurrently receive hello messages on its Ethernet port, its radio port, and its IP tunnel port.

  • Page 104: Internet Group Management Protocol (Igmp)

    IP multicast group by enabling IGMP and by defining a Class D IP multicast address. The Internet Assigned Numbers Authority has allocated 224.0.1.65 for Intermec’s inter-access-point protocol (IAPP). You must enter this address in the IP address list in the root access point. (Note that the address list may contain other IP addresses.) and in the Multicast Address field in the other access points.

  • Page 105: Originating Ip Tunnels

    Configuring the Spanning Tree Originating IP Tunnels The creation of tunnels between the root access point on the home IP subnet and access points on remote IP subnets is controlled by three operational parameters: • Enabled/disabled IP ports. A tunnel can never be established on a disabled IP port. •...

  • Page 106: Ip Addressing For End Devices

    The Intermec NNL protocol is a simple Non-routable Network Layer protocol that is used to carry high-layer data in a local area network environment. An Intermec NNL gateway forwards NNL traffic to non-NNL hosts such as TCP/IP hosts. You can use the default flooding and bridging settings, and minimize triangular routing, if NNL gateways are located on the home subnet.
  • Page 107 Configuring the Spanning Tree MAC frames originating on the home IP subnet are encapsulated in the root access point, forwarded through the IP network, unencapsulated by the access point at the remote end of the IP tunnel, and forwarded to the appropriate access point (if necessary) for delivery to the destination end device.

  • Page 108: Outbound Frames

    MobileLAN access 21XX System Manual Outbound Frames Data frames are forwarded outbound through an IP tunnel if • an end device is known to be attached to an access point on a remote IP subnet. • the frame type is enabled in the Tunnel Filters menu. Unicast frames are not flooded.
  • Page 109 Determine if you need to enable bridging on remote subnets. For example, bridging must be enabled if an Intermec NNL gateway is attached to the remote subnet. For help, see “Configuring the Spanning Tree Parameters” earlier in this chapter. The designated bridge candidates must have permanent IP addresses and must be able to receive IP hello messages from the root access point.
  • Page 110 5. In the Multicast Address field, enter the multicast address. Unless you have your own IP multicast address, the Internet Assigned Numbers Authority has allocated 224.0.1.65 for Intermec’s inter-access-point protocol (IAPP). You should use this default multicast address. 6. Click Submit Changes to save your changes. To activate your changes, from the menu bar click Save/Discard Changes and then click Save Changes and Reboot.

  • Page 111: Configuring Ip Tunnel Filters

    Configuring the Spanning Tree 3. Enter the IP unicast addresses of the access points that can be the endpoints of IP tunnels. 4. Click Submit Changes to save your changes. To activate your changes, from the menu bar click Save/Discard Changes and then click Save Changes and Reboot. For help, see “Saving Configuration Changes”...

  • Page 112: Using Ip Tunnel Frame Type Filters

    MobileLAN access 21XX System Manual 3. Click Submit Changes to save your changes. To activate your changes, from the menu bar click Save/Discard Changes and then click Save Changes and Reboot. For help, see “Saving Configuration Changes” in Chapter 1. Using IP Tunnel Frame Type Filters The IP port automatically provides some filtering for end devices.
  • Page 113 Configuring the Spanning Tree To use IP tunnel frame type filters 1. From the main menu, click IP Tunnels and then click Tunnel Filters. 2. Click Frame Type Filters. The Frame Type Filters screen appears. 3. In each frame type field, click the down arrow on the right side of the Action field and set the action to Pass or Drop.
  • Page 114 MobileLAN access 21XX System Manual The following table explains various frame type filters. Frame Type Explanation DIX IP TCP Ports Primary Internet Protocol Suite (IP) transport protocols. DIX IP UDP Ports SNAP IP TCP Ports SNAP IP UDP Ports DIX IP Other Protocols IP protocols other than TCP or User Datagram Protocol (UDP).

  • Page 115: Using Predefined Subtype Filters

    Configuring the Spanning Tree Using Predefined Subtype Filters You can configure the access point to pass or drop certain predefined frame subtypes. To configure predefined subtype filters 1. From the main menu, click IP Tunnels and then click Tunnel Filters. 2.

  • Page 116: Customizing Subtype Filters

    MobileLAN access 21XX System Manual Customizing Subtype Filters You can define output filters that restrict customized frame subtypes that can pass through an IP tunnel. Frames can be filtered by the DIX, 802.2, or 802.3 SNAP type, the IP protocol type, or the TCP or UDP port number. By default, the filters drop all protocol types except the NNL DIX Ethernet type (hexadecimal 875B).

  • Page 117: Ip Tunnel Filter Examples

    Configuring the Spanning Tree 3. Click the down arrow on the right side of the Action field and choose Pass or Drop. 4. Click the down arrow on the right side of the SubType field and choose the customizable frame subtype. For help, see the next table. 5.

  • Page 118: Example 1

    MobileLAN access 21XX System Manual IP Tunnel Filter Examples Graphic IP Host Novell Server AP 1 (Root) IPX Router Primary LAN AP 3 AP 2 Wireless IP Host IPX Host Devices AP 4 AP 5 AP 6 Secondary LAN 21XXT027.eps Example 1 APs 1, 3, 5, and 6 service only wireless IP devices.
  • Page 119 Configuring the Spanning Tree Ethernet Frame Type Filters Screen Frame Type Filter Action Scope DIX-IP-TCP Ports Pass DIX-IP-UDP Ports Pass DIX-IP-Other Protocols Pass SNAP-IP-TCP Ports Pass SNAP-IP-UDP Ports Pass 4-31...

  • Page 120: Example 3

    MobileLAN access 21XX System Manual Go to the Predefined Subtype Filters screen and set the 802.2-IPX-RIP field to Drop to drop 802.2, DIX, and 802.3 frames. Example 3 If you have a Windows NT server and want to use DHCP for automatic address assignment for an end device on a remote subnet, you need to set the following filters to allow for the necessary IP tunneling.

  • Page 121: Comparing Ip Tunnels To Mobile Ip

    Configuring the Spanning Tree Comparing IP Tunnels to Mobile IP The Internet Engineering Task Force developed RFC 2002, IP Mobility Support, commonly referred to as mobile IP, to provide mobility for IP hosts. Mobile IP is designed primarily to address the needs of wireless end devices that may move between geographically separated locations.
  • Page 122 MobileLAN access 21XX System Manual 4-34...

  • Page 123: Configuring The Radios

    Configuring the Radios...
  • Page 124 MobileLAN access 21XX User’s Manual...

  • Page 125: About The Radios

    Configuring the Radios This chapter explains how to configure the radios so that they work with your wireless end devices. It also provides some general guidelines to configuring point-to-point bridges and WAPs. About the Radios The MobileLAN access 21XX family of access points consists of a group of multiport Ethernet bridges.

  • Page 126: Configuring The Ieee 802.11B Radio

    MobileLAN access 21XX System Manual Configuring the IEEE 802.11b Radio The IEEE 802.11b radio will communicate with other 802.11b radios that have the same • SSID (Network Name). • WEP keys. For help, see “Using MobileLAN secure (802.1x)” and “Using Static WEP Keys”...
  • Page 127 Configuring the Radios The following table explains each parameter. Parameter Explanation Port Control Enables or disables the 802.11b port. SSID (Network The 802.11b radio communicates with other 802.11b radios with the Name) same network name. Use this parameter to assign a network name to the access point, and then assign the same network name to the wireless end devices that will connect to the access point.
  • Page 128 MobileLAN access 21XX System Manual Worldwide Frequencies for the 802.11b Radio Channel ETSI France Japan Israel 2412 2412 2412 2417 2417 2417 2422 2422 2422 2422 (default) (default) (default) (default) 2427 2427 2427 2432 2432 2432 2437 2437 2437 2442 2442 2442 2447...

  • Page 129: Configuring 802.11B Radio Advanced Parameters

    Configuring the Radios Configuring 802.11b Radio Advanced Parameters You can configure other advanced parameters for the 802.11b radio, such as Data Rate, Medium Reservation, and Microwave Oven Robustness. To configure other advanced parameters 1. From the main menu, click IEEE 802.11b Radio. The IEEE 802.11b Radio screen appears.
  • Page 130 MobileLAN access 21XX System Manual Use the following table to configure advanced parameters. Parameter Description Data Rate Choose the rate at which the access point transmits data. In general, higher speeds mean shorter range and lower speeds mean longer range. You can set this rate to 11, 5.5, 2, or 1 Mbps.

  • Page 131: Configuring A Mobilelan Voice Network

    Configuring the Radios 802.11b Radio Advanced Parameters Table (continued) Parameter Description DTIM Period Specifies the number of beacon frames to skip before including a DTIM (delivery traffic indication message) in a beacon frame. Setting a higher DTIM period may conserve battery life in a wireless end device, but it may increase response time.

  • Page 132: Configuring The Ieee 802.11A Radio

    MobileLAN access 21XX System Manual 3. Click Submit Changes to save your changes. 4. From the IEEE 802.11b Radio menu, click Advanced Configuration. The Advanced Configuration screen appears. 5. Configure these advanced parameters: • Enable the Data Rate Fallback parameter. •...
  • Page 133 Configuring the Radios 2. Configure the parameters for the radio. For help, see the next table. 3. Click Submit Changes to save your changes. To activate your changes, from the menu bar click Save/Discard Changes and then click Save Changes and Reboot. For help, see “Saving Configuration Changes”...
  • Page 134 MobileLAN access 21XX System Manual Worldwide Frequencies for the 802.11a Radio Channel ETSI France Japan Israel 5180 (default) 5200 5220 5240 5260 5280 5300 5320 FCC countries include the United States, Canada, China, Taiwan, India, Thailand, Indonesia, Malaysia, Hong Kong, and most South American countries. The 802.11a channels that are allowed in a given country may change without notice.

  • Page 135: Configuring 802.11A Radio Advanced Parameters

    Configuring the Radios Configuring 802.11a Radio Advanced Parameters You can configure other advanced parameters for the 802.11a radio, such as Data Rate and Medium Reservation. To configure other advanced parameters 1. From the main menu, click IEEE 802.11a Radio. The IEEE 802.11a Radio screen appears.
  • Page 136 MobileLAN access 21XX System Manual Use the following table to configure advanced parameters. Parameter Description Data Rate Choose the rate at which the access point transmits data. In general, higher speeds mean shorter range and lower speeds mean longer range. If you choose the Speed Mode to be 802.11 compliant, you can set this rate to 54, 48, 36, 24, 12, or 6 Mbps.

  • Page 137: Configuring The Wli Forum Openair Radio

    • subchannel. Caution Intermec recommends that you set the security ID to a value other than null. Failure to change the default setting could expose your network to a security breach by an unauthorized wireless device. Conseil Intermec vous recommande de régler l'ID de sécurité sur une valeur autre que Nul.
  • Page 138 MAC Configuration Adjusting this parameter may enhance the performance of your radio. Intermec recommends that you only change the MAC Configuration parameter under the direction of Intermec Technical Support. Default Uses the factory settings for the radio protocol. You should use this setting for normal operations.

  • Page 139: Setting Manual Mac Parameters

    Occasionally, you may need to fine-tune your OpenAir radio MAC parameters. Note: An inefficient MAC Configuration parameter can adversely affect the performance of your wireless LAN. Intermec recommends that you only change these MAC Configuration settings under the direction of Intermec Technical Support.
  • Page 140 MobileLAN access 21XX System Manual The following table explains each manual MAC parameter. Parameter Explanation Hop Period You can only set this parameter if this radio is a master radio. Specifies how long the master radio stays on a frequency in the hopping sequence before stepping to the next frequency.
  • Page 141 Configuring the Radios Manual MAC Parameters Table (continued) Parameter Explanation Normal Ack Retry Controls the number of times an unfragmented frame is resent unsuccessfully before fragmenting. You can set the parameter to a value from 1 to 255. The default is 255, which allows the radio to choose an optimal value.

  • Page 142: Configuring The 902 Mhz Radio

    MobileLAN access 21XX System Manual Configuring the 902 MHz Radio The 902 MHz radio will communicate with other 902 MHz radios that have the same • LAN ID. For help, see “Configuring the Spanning Tree Parameters” in Chapter 4. • Mode-Channel.
  • Page 143 Multicast Filter Determines if this radio can receive and send multicast packets. File Name Specifies the name of the radio’s driver software. Intermec recommends that you change this name only when directed to do so by Intermec Technical Support. Hello Period Controls how frequently the access point broadcasts hello packets on the 902 MHz port.

  • Page 144: Configuring The S-Uhf Radio

    MobileLAN access 21XX System Manual Configuring the S-UHF Radio 1. From the main menu, click S-UHF radio. The S-UHF Radio screen appears. 2. Configure the S-UHF radio. For help, see the next table. 3. Click Submit Changes to save your changes. To activate your changes, from the menu bar click Save/Discard Changes and then click Save Changes and Reboot.
  • Page 145 Determines if this radio can receive and send multicast packets. File Name Specifies the name of the radio’s driver software. Change this name only when directed to do so by Intermec Technical Support. Hello Period Controls how frequently the access point broadcasts hello packets on the S-UHF port.

  • Page 146: Configuring Waps

    Host 21XXT038.eps Intermec recommends that you install no more than two WAPs for each wired access point. Before you can create wireless hops, both the WAP and the wired access point must be on the same IP subnet. Also, the radios in both the WAP and the wired access point must be communicating with each other.
  • Page 147 Configuring the Radios To configure the master radio (in the wired access point) 1. From the main menu, click the link corresponding to the radio that you are configuring. 2. Click Wireless Bridging. The Wireless Bridging screen appears. 3. Click the down arrow on the right side of the Node Type field and choose Master and then click Submit Changes.
  • Page 148 MobileLAN access 21XX System Manual Wireless Bridging Screen - Station (continued) 3. Click the down arrow on the right side of the Node Type field and choose Station. Wireless hops are automatically disabled. Click Submit changes to save your changes. 4.

  • Page 149: Example: Configuring An Openair Wap

    Configuring the Radios b. In the Channel and Subchannel fields, enter the channel and subchannel of all master radios with which this station can communicate. 4. Click Submit Changes to save your changes. To activate your changes, from the menu bar click Save/Discard Changes and then click Save Changes and Reboot. For help, see “Saving Configuration Changes”...

  • Page 150: Configuring Point-To-Point Bridges

    MobileLAN access 21XX System Manual Configuring Point-to-Point Bridges In your environment, you may have point-to-point bridges, which send data from wireless end devices on a secondary LAN to a primary LAN. This data is sent via a wireless hop. Wireless hops are formed when data from wireless end devices move from one access point to another access point through the radio ports.
  • Page 151 Configuring the Radios Note: If you are using a 902 MHz access point, it only needs one 902 MHz radio. This radio can simultaneously be a master and a station. It will create wireless hops automatically when it cannot communicate to the wired network. You need to set the root priority of the master radio to a number that is greater than the root priority of the station radio.
  • Page 152 MobileLAN access 21XX System Manual 9. Click the down arrow on the right side of the Secondary LAN Flooding field and choose Disabled. 10. Click Submit Changes to save your changes. To activate your changes, from the menu bar click Save/Discard Changes and then click Save Changes and Reboot. For help, see “Saving Configuration Changes”...

  • Page 153: Example: Configuring An 802.11B Point-To-Point Bridge

    Configuring the Radios Example: Configuring an 802.11b Point-to-Point Bridge In this example, each access point only has one 802.11b radio. All 802.11b radios in the bridges and end devices must have the same SSID (Network Name) and the same WEP encryption.
  • Page 154 MobileLAN access 21XX System Manual The advantages and disadvantages of using this configuration are listed below. Advantages Disadvantages Does not require WEP encryption. Requires two 802.11b radios in the wired access point and two in the WAP. Wireless end devices can roam between the Limited to a single wireless hop if end access points forming the wireless hop.

  • Page 155: Example 2: Configuring A Wireless Hop From A Remote Lan

    Configuring the Radios Example 2: Configuring a Wireless Hop From a Remote LAN In this example, there are two access points in the 802.11b network: the root access point is connected to the primary LAN and the other access point is connected to a secondary (remote) LAN.

  • Page 156: Example 3: Configuring Wireless Hops With Wep

    MobileLAN access 21XX System Manual Example 3: Configuring Wireless Hops With WEP In this example, there are two access points in the 802.11b network: one access point is connected to the wired LAN and the other is a WAP. Wireless end device can roam between the wired access point and the WAP.
  • Page 157 Configuring the Radios 5. In the WAP, configure the Ethernet Address Table. a. From the main menu, click Ethernet and then click Address Table. b. Enter the MAC address of each wireless end device that uses this WAP to communicate to the primary LAN. 6.
  • Page 158 MobileLAN access 21XX System Manual 5-36...

  • Page 159: Setting Up Security

    Setting Up Security...
  • Page 160 MobileLAN access 21XX System Manual...

  • Page 161: About Security

    Setting Up Security This chapter explains how to use features that are available in the MobileLAN access family to ensure that you have a secure wireless network. About Security There are several levels of security that you can implement in the access points. 1.
  • Page 162 MobileLAN access 21XX System Manual To enable or disable access methods 1. From the main menu, click Security. The Security screen appears. 2. Enable or disable the access methods that users can use to connect to the access point. For help, see the next table. 3.

  • Page 163: Setting Up Logins

    Setting Up Security Setting Up Logins To ensure login security for configuring or maintaining the access points, you should either use a password server (typically a RADIUS server) or immediately change the default user name and password. To use the RADIUS password server, you must have the following: •...
  • Page 164 MobileLAN access 21XX System Manual To set up logins 1. From the main menu, click Security and then click Passwords. The Passwords screen appears. 2. Enable or disable Radius Authorization. If you enable Radius Authorization and then click Submit Changes, this screen appears. If you disable RADIUS authorization and then click Submit Changes, this screen appears.
  • Page 165 Determines if a user can use the service password to connect to this access point. Gives read-only access to the access point. Intermec recommends that you do not disable the service password. Enabling this password may help Intermec Technical Support help you with your installation.

  • Page 166: Configuring The Internal Radius Server

    MobileLAN access 21XX System Manual Configuring the Internal RADIUS Server The access point has an internal RADIUS password server you can use to authorize user name and password logins. By using this password server you do not need to buy a separate server to authorize logins, but you are limited to 70 users.
  • Page 167 Setting Up Security 5. From the Security menu, click Internal RADIUS Server and then click Access Point Login Database. The Access Point Login Database screen appears. 6. In each User Name and Password field, enter a user name and password of all the users who can log into this access point with read/write privileges.

  • Page 168: Using Mobilelan Secure (802.1X)

    MobileLAN access 21XX System Manual Using MobileLAN secure (802.1x) MobileLANsecure is Intermec’s name for its implementation of the 802.1x security standard in the MobileLAN access 21XX products. MobileLAN secure increases security between the access points and the wireless end devices by using an 802.1x authentication server (typically a RADIUS server) to authenticate each device’s initial...
  • Page 169 Setting Up Security Note: Currently, you cannot use this 802.1x authentication over wireless hops. Note: Since 802.1x authentication uses rotating WEP keys that are automatically generated, you do not configure IEEE 802.11b Radio WEP or IEEE 802.11a Radio WEP. You only configure these parameters if you are using static WEP keys. To configure MobileLAN secure 1.
  • Page 170 Enter a key that the access points use to encrypt and sign security context exchanges. This key must be the same in all access points and can contain from 1 to 32 characters. Intermec recommends that this key contain at least 16 characters. You can enter the key in ASCII or in hexadecimal.

  • Page 171: Using Static Wep Keys

    Setting Up Security Using Static WEP Keys At a minimum, you can use static WEP keys (WEP 64 or WEP 128) to provide security between the access points and the wireless end devices. To use static WEP keys, your 802.11b or your 802.11a radios must support WEP encryption. For WEP 64, you enter five ASCII characters or five hex pairs for the WEP keys.
  • Page 172 MobileLAN access 21XX System Manual 4. Click Submit Changes to save your changes. To activate your changes, from the menu bar click Save/Discard Changes and then click Save Changes and Reboot. For help, see “Saving Configuration Changes” in Chapter 1. The following table explains each parameter.

  • Page 173: Managing, Troubleshooting, And Upgrading The 21Xx

    Managing, Troubleshooting, and Upgrading the 21XX...
  • Page 174 MobileLAN access 21XX System Manual...

  • Page 175: Managing The 21Xx

    (SNMP); that is, you access the access point from an SNMP management station. Contact your Intermec representative if you need to obtain a copy of the MIB. Before you can use an SNMP management station, you must define the access point’s...
  • Page 176 MobileLAN access 21XX System Manual To configure the SNMP community strings 1. From the menu, click Network Management and then click Community Strings. The Community Strings screen appears. 2. Configure the SNMP community parameters. For help, see the next table. 3.

  • Page 177: Using Intermec Device Registration Service (Idrs) Servers

    IP address to discover the active devices on a network. This discovery process is time-consuming and uses valuable network bandwidth. When you use IDRS, however, each Intermec device automatically registers with an IDRS server on startup; the IDRS server then maintains a database of all registered devices.

  • Page 178: Maintaining The 21Xx

    From the Maintenance menu, you can view different parameters configured for the access point, including port statistics, connections, and a configuration summary. The information on these screens may be needed when you call Intermec Technical Support. Understanding the LEDs Lighting Sequence When the access point boots, the LEDs flash as it performs internal diagnostics.

  • Page 179: Viewing Ap Connections

    Managing, Troubleshooting, and Upgrading the 21XX After the access point successfully boots, the LEDs display the following pattern: Power Wireless #1 Wireless #2 Wired LAN Root/Error Flashes Flashes (if Flashes Flashes if the access point is radio configured as the root installed) Viewing AP Connections The AP Connections screen shows information about the devices in the spanning tree.

  • Page 180: Viewing Port Statistics

    MobileLAN access 21XX System Manual Viewing Port Statistics The Port Statistics screen shows the total number of frames and bytes that the access point has transmitted and received since it was last booted. To view port statistics • From the menu, click Maintenance and then click Port Statistics. The Port Statistics screen appears.

  • Page 181: Viewing The Configuration Summary

    Managing, Troubleshooting, and Upgrading the 21XX Viewing the Configuration Summary The Configuration Summary screen summarizes the major configuration settings and installed hardware for the access point. To view the configuration summary • From the menu, click Maintenance and then click Configuration Summary. The Configuration Summary screen appears.

  • Page 182: Viewing The About This Access Point Screen

    MobileLAN access 21XX System Manual Viewing the About This Access Point Screen This screen shows information about the access point including software versions, radio versions, and MAC addresses. To view About this Access Point • From the menu, click Maintenance and then click About this Access Point. The About this Access Point screen appears.

  • Page 183: Using The Mobilelan Access Utility

    Managing, Troubleshooting, and Upgrading the 21XX Using the MobileLAN access Utility For help installing the MobileLAN access utility, see “Using the MobileLAN access Utility” in Chapter 1. To restore the access point to the default configuration 1. Start the utility. 2.

  • Page 184: Using The Web Browser Interface

    MobileLAN access 21XX System Manual Using the Web Browser Interface 1. In the menu bar, click Save/Discard Changes. This screen appears. 2. Click Restore Factory Defaults. Under Pending Changes, you will see a list of what parameters need to be changed. 3.

  • Page 185: Troubleshooting The 21Xx

    Getting Help With Your Installation The access points are designed to be easy to install and configure; however, you may need to call Intermec Technical Support if you have problems. Before calling, be sure you can answer the following questions: •...
  • Page 186 The Ping Utility screen does The Web browser you are using does not have Java support. not appear when you click a Intermec recommends that you use Internet Explorer v3.0 or MAC address or an IP address later or Netscape Communicator v4.0 or later.
  • Page 187 Managing, Troubleshooting, and Upgrading the 21XX General Troubleshooting (continued) Problem/Question Possible Solution/Answer You cannot connect to the Verify that you did not disable the SNMP Access field in the access point using an SNMP Security screen. management station. • The end device cannot connect Choose AP Connections from the Maintenance menu to the network.
  • Page 188 MobileLAN access 21XX System Manual General Troubleshooting (continued) Problem/Question Possible Solution/Answer The end devices are unable to Set the Unicast Flood Mode to Hierarchical. For more roam between 21XX and 011X information, see “Configuring Global Flooding” in devices. Chapter 4. You cannot originate an IP Click TCP/IP Settings and verify that the IP Router tunnel to an access point on a...

  • Page 189: Troubleshooting The Radios

    These error messages may appear for either radio A or radio B. Error Message Explanation Couldn’t read country code The radio may be faulty. Contact your Intermec from radio A representative. Invalid country code in string The country code in the configuration matrix string does not for radio A match the country code in the radio in the access point.

  • Page 190: Using Radio Mac Ping (802.11B Radios)

    MobileLAN access 21XX System Manual Using Radio MAC Ping (802.11b Radios) Radio MAC Ping runs at the MAC sublayer of the Data Link layer, thus allowing you to ping any 802.11b device that is connected to the access point. Radio MAC Ping can help you determine the connectivity and signal strength of an 802.11b radio.

  • Page 191: Using Icmp Echo

    Managing, Troubleshooting, and Upgrading the 21XX 2. Click a MAC address hyperlink. The access point pings the device and then the Ping Utility screen appears showing the results. 3. Click Return to connections to return to the AP Connections screen. Using ICMP Echo ICMP (Internet Control Message Protocol ) echo lets you ping devices using their IP address.
  • Page 192 MobileLAN access 21XX System Manual To use ICMP echo 1. From the menu, click Maintenance and then click AP Connections. The AP Connections screen appears. 2. Click an IP address link. The access point pings the device and then the Ping Utility screen appears showing the results.

  • Page 193: Reloading Access Point Files

    Managing, Troubleshooting, and Upgrading the 21XX Reloading Access Point Files If the access point loses all its files except the boot ROM code, the Wireless #2 LED and the Root LED are flashing at the same time. You will not be able to ping the access point and you cannot establish a Telnet session to the access point.
  • Page 194 MobileLAN access 21XX System Manual MobileLAN access Utility Screen 4. In the Temporary IP Address field, enter a temporary IP address for the access point you need to recover. You can use any IP address that is valid on your network. 5.
  • Page 195 Managing, Troubleshooting, and Upgrading the 21XX Command Console Screen 3. At the prompt, type to start the TFTP server. TFTP SERVER START 4. Use TFTP to copy the files listed in the table on the previous page to the access point.

  • Page 196: Upgrading The 21Xx

    TFTP transfer via a Web browser or a Telnet session. For more information, see “Using TFTP” later in this section. To copy the software release to your PC 1. Using your Web browser, navigate to mobilelan.intermec.com and then click Software Downloads. 2. Download the zipped software upgrade file to your PC.
  • Page 197 Managing, Troubleshooting, and Upgrading the 21XX To upgrade the access point software 1. Start the utility. 2. In the Upgrade File Location field, enter the path and filename of the upgrade file (AP*WEB.BIN) or click Browse to find the file. For example, AP170WEB.BIN. 3.
  • Page 198 MobileLAN access 21XX System Manual c. In the Server IP Address field, enter the IP address of the PC contains the software release and that is running the utility. d. Click the down arrow on the right side of the Start Time field and choose when you want the upgrade to start.

  • Page 199: Using A Web Browser Interface

    Managing, Troubleshooting, and Upgrading the 21XX Using a Web Browser Interface You can use a Web browser interface to upgrade the access points one at a time. In other words, for each access point you want to upgrade, you will need to establish a Web browser session with it, upgrade its software, save the new configuration, and reboot it.

  • Page 200: Using A Communications Program

    MobileLAN access 21XX System Manual Using a Communications Program You can use a communications program (such as HyperTerminal) to upgrade the access points one at a time. You will need to connect each access point to your PC using an RS-232 null-modem cable and configure the serial port communications parameters on your PC.
  • Page 201 Managing, Troubleshooting, and Upgrading the 21XX To upgrade a 2101, 2100, or 2102 1. At the service prompt (service>), type and press Enter. The file directory appears. Scroll up until you see a section similar to the following: Startup Segment: This startup = 1, Next startup = 1 Data Segment: This startup = 3, Next startup = 3...
  • Page 202 MobileLAN access 21XX System Manual 5. Copy the data files to the inactive data segment. a. Type and press Enter. A series of Cs appears on your screen. fx 3 b. As the Cs are appearing, send all the data files using YMODEM protocol to the access point.

  • Page 203: Using Tftp

    Managing, Troubleshooting, and Upgrading the 21XX 3. Activate the files by typing and press Enter. A ‘P’ appears when the operation is complete. 4. Type x to return to the access point prompt (ap>). 5. Type b and press Enter to reboot the access point. You may need to reconfigure the access point for your installation.
  • Page 204 MobileLAN access 21XX System Manual b. Click TFTP Server. The page goes to the TFTP Server configuration section. c. Click Start Server. 2. Configure the TFTP client on the access point that you want to upgrade. a. From the menu bar, click File System. The Software Upgrade screen appears. Note: If the access point software is earlier than version 1.70, click Software Upgrade (TFTP).
  • Page 205 Managing, Troubleshooting, and Upgrading the 21XX To upgrade the access point using a TFTP server on your PC and the Web browser interface 1. From the menu bar, click File System. The Software Upgrade screen appears. Depending on which access point you are upgrading, your screen may look different.
  • Page 206 MobileLAN access 21XX System Manual 3. Configure the following parameters: Parameter Description Server IP Address Enter the IP address of your TFTP server. The TFTP server has the upgrade file on it (usually your PC). Script File Name Enter the pathname and filename of the upgrade file (UPNOPATH.DNL) on the TFTP server.
  • Page 207 Managing, Troubleshooting, and Upgrading the 21XX 4. Use the sdvars set serveripaddress command to specify the IP address of the TFTP server (usually your PC) by typing: sdvars set serveripaddress IPaddress where IPaddress is the IP address of the TFTP server. 5.

  • Page 208: Troubleshooting The Upgrade

    MobileLAN access 21XX System Manual Troubleshooting the Upgrade Each access point on a wired LAN requires approximately three minutes to upgrade (it takes slightly longer for wireless access points). The Web browser screen updates every 30 seconds as the upgrade progresses and shows the final status when all upgrades are complete.

  • Page 209: Additional Access Point Features

    Additional Access Point Features...
  • Page 210 MobileLAN access 21XX User’s Manual...

  • Page 211: Understanding The Access Point Segments

    2106. Note: Certain functions available through the AP monitor can erase the access point configuration. Intermec strongly recommends that you only use the AP monitor when absolutely necessary. For example, you might use the AP monitor to upgrade the access point software or when instructed to do so by Intermec Technical Support.

  • Page 212: Using Ap Monitor Commands

    MobileLAN access 21XX System Manual Using AP Monitor Commands You can display a list of AP monitor commands on the screen anytime you see the ap prompt. To list AP monitor commands • Press any key (except the letter B, which reboots the access point), and then press Enter.

  • Page 213: Using Content Addressable Memory (Cam) Mode Commands

    CAM, which is controlled by the Field Programmable Gate Array (FPGA), filters packets based on the radio’s capability. Because the commands can cause undesirable results if not properly executed, you should contact Intermec Technical Support for assistance if you are unsure about the proper procedure to use.

  • Page 214: Using Test Mode Commands

    Within the AP monitor, Test mode lets you perform certain test functions. Because the commands can cause undesirable results if not properly executed, you should contact Intermec Technical Support for assistance if you are unsure about the proper procedure to use.

  • Page 215: Using Service Mode Commands

    Additional Access Point Features To display test commands • Type any letter or number other than B and press Enter. The test commands appear on the screen. Using Service Mode Commands In Service mode, you can perform file functions and segment functions such as deleting a file, downloading a file using the Ymodem protocol, and erasing a segment.
  • Page 216 MobileLAN access 21XX System Manual To list service commands • Press any key (except the letter B, which reboots the access point), and then press Enter. The service commands appear on the screen. Many of the commands that are available in Service mode are also available in the AP monitor or Console Command mode.
  • Page 217 Additional Access Point Features FB Command (continued) You can use an asterisk instead of a segment name if you want to leave that segment unchanged. For example, to leave the active boot segment unchanged and make segment 4 the active data segment, you could enter: FB * 4 After loading software into the access point a common task is to activate the new software.
  • Page 218 MobileLAN access 21XX System Manual FDEL Command (continued) Note: When you use the FDEL command, the file is marked as invalid and remains in the file system. To reclaim the file space, you must erase the entire segment. Use the FE command to erase a segment.

  • Page 219: Using Command Console Mode

    Additional Access Point Features Purpose: Downloads a file using Ymodem batch protocol into the flash segment that is specified Syntax: where s is segment 1, 2, 3, or 4. Purpose: Loads the FPGA configuration file into the access point. If you are directed to change the FPGA firmware in the access point, use this command.

  • Page 220: Using The Commands

    MobileLAN access 21XX System Manual Command Console Mode Screen To exit Command Console mode • At the prompt, type exit You return to the Maintenance menu. Using the Commands Several of these commands require that you enter filenames. To indicate the segment where the file is located, precede the filename with either a segment number or name followed by a colon.
  • Page 221 Additional Access Point Features FB Command (continued) You can use an asterisk instead of a segment name if you want to leave that segment unchanged. For example, to leave the active boot segment unchanged and make segment 4 the active data segment, you could enter: FB * 4 After loading software into the access point a common task is to activate the new software.

  • Page 222: Using Tftp Commands

    MobileLAN access 21XX System Manual Purpose: Erases the files in a particular segment. To recover the files after they have been erased, you must reload them from another source. Note: You must execute the FE command before you execute a TFTP transfer. Syntax: FE s where s is the name or number of the segment to be erased.
  • Page 223 Additional Access Point Features TFTP GET Purpose: TFTP client requests a file from the TFTP server. Note: You must use the FE command to erase the segment before you execute a TFTP GET command. If you do not erase the segment, you may get a “can’t write file” error. Syntax: TFTP GET IPaddress foreignfilename localfilename where:...
  • Page 224 MobileLAN access 21XX System Manual TFTP PUT Purpose: Copies a file from a TFTP client to the TFTP server or to another access point. Syntax: TFTP PUT IPaddress foreignfilename localfilename where: IPaddress is the IP address of the server. You can use an asterisk (*) here if you want to use the value in the serveripaddress.
  • Page 225 Additional Access Point Features TFTP SERVER START Purpose: Use this command to enable the access point to act as a server. You can enable one access point to act as a TFTP server and download files to additional access points. Syntax: TFTP SERVER START After you issue this command, the access point responds to TFTP client requests that...

  • Page 226: Using Sdvars Commands

    MobileLAN access 21XX System Manual Using sdvars Commands Use sdvars commands to manipulate certain software download variables. Sdvars commands support both GET and SET arguments. You can enter sdvars commands to GET a software download object, and then issue the sdvars command using the SET argument to assign the object a specified value.
  • Page 227 Additional Access Point Features sdvars set starttime Command (continued) Syntax: sdvars set starttime dd : hh : mm : ss where dd:hh:mm:ss is how far in the future the reboot is to begin and is days. is hours. is minutes. is seconds.
  • Page 228 MobileLAN access 21XX System Manual sdvars set terminate Purpose: Sets the internal variable terminate to a specified value. Use terminate to stop a countdown process in the access point. If either starttime or nextpoweruptime is counting down, setting this variable stops the timer and halts the countdown process. Note: You should use caution when using this command.

  • Page 229: Creating Script Files

    Script files are ASCII text files with a 32-byte file system header appended. You may need to contact your local Intermec representative for a copy of the header file called filehdr.exe. Follow these rules when creating script files: •...
  • Page 230 *\data\discinca.dnl id: file tftp get *\data\falcon_.dnl id: file tftp get *\data\help.dnl id: file tftp get *\data\hlp.dnl id: file tftp get *\data\intermec.dnl id: file tftp get *\data\menu.dnl id: file tftp get *\data\sftdwnl.dnl id: file tftp get *\data\welcome.dnl id: file tftp get *\data\write.dnl id:...

  • Page 231: Specifications And Default Settings

    Specifications and Default Settings...
  • Page 232 adsf...
  • Page 233 Specifications and Default Settings This appendix provides specifications and system defaults for reference purposes only. Actual product performance and compliance with local telecommunications regulations may vary from country to country. Intermec only ships products that are type approved in the destination country. Specifications...
  • Page 234 MobileLAN access 21XX System Manual Specifications (continued) 2100 Height 95 mm (3.75 in) Length 355 mm (14.0 in) Width 236 mm (9.3 in) Weight 2.63 kg (5.8 lb) ∼100 to 240V Electrical 1.0 to 0.5A 50 to 60 Hz Operating Temperature Standard unit -25°C to +70°C (-13°F to +158°F) Heater module (optional)
  • Page 235 Specifications and Default Settings Specifications (continued) 2102 Height 9.32 cm (3.67 in) Length 14.66 cm (5.77 in) Width 3.53 cm (1.39 in) Weight 232 g (0.51 lb) ∼100 to 240V Electrical 1.0A 50 to 60 Hz Operating temperature -20°C to +65°C (-4°F to +149°F) Storage temperature -40°C to +70°C (-40°F to +158°F) Humidity (non-condensing)
  • Page 236 MobileLAN access 21XX System Manual Specifications (continued) 2106 Height 9.32 cm (3.67 in) Length 14.66 cm (5.77 in) Width 3.53 cm (1.39 in) Weight 232 g (0.51 lb) ∼100 to 240V Electrical 1.0A 50 to 60 Hz Operating temperature 0°C to +45°C (32°F to +113°F) Storage temperature -20°C to +70°C (-4°F to +158°F) Humidity (non-condensing)

  • Page 237: Radio Specifications

    Specifications and Default Settings Radio Specifications IEEE 802.11b Frequency band 2.4 to 2.5 GHz worldwide Type Direct sequence, spread spectrum Modulation Direct sequence, spread spectrum (CCK, DQPSK, DBPSK) Power output 32 mW (15 dBm) Data rate 11 Mbps (High), 5.5 Mbps (Medium), 2 Mbps (Standard), 1 Mbps (Low) with automatic fallback for increased range Channels 11 (North America), 13 (Europe), 4 (France), 14 (Japan).

  • Page 238: Ieee 802.11A

    MobileLAN access 21XX System Manual IEEE 802.11a Frequency band 5.15 to 5.35 GHz Type Direct sequence, spread spectrum Power output 40mW Data rate 802.11 compliant mode: 54 Mbps, 48 Mbps, 36 Mbps, 24 Mbps, 12 Mbps, 6 Mbps with automatic fallback for increased range Turbo mode: 72 Mbps, 48 Mbps, 36 Mbps, 24 Mbps, 12 Mbps with automatic fallback for increased range...

  • Page 239: 902 Mhz

    Specifications and Default Settings 902 MHz Frequency band 902 to 928 MHz (not available in Europe) Type Direct sequence, spread spectrum Power output Minimum 24dBm (250 mW) Typical 25.5dBm (350 mW) Maximum 27dBm (500 mW) Data rate 90, 225, or 450 Kbps (depends on installation) Channels 7 @ 90 Kbps, 1 @ 225, or 450 Kbps Range...

  • Page 240: Antennas And Antenna Accessories

    MobileLAN access 21XX System Manual Antennas and Antenna Accessories This table identifies many of the Intermec antennas and antenna accessories for the radios. Contact your local Intermec representative for detailed information. Description Part No. Description 21XX antennas 067261 Antenna, 2.4 GHz, 3 dBi Mini Omni 067262 Antenna, 2.4 GHz, 5 dBi Dual Flat...
  • Page 241 Specifications and Default Settings Antennas and Antenna Accessories (continued) Description Part No. Description 2100 antennas 805-430-001 Antenna, S-UHF, 5 dB Mag Mount (includes 3.67 m (continued) (12 ft) cable, no extensions) 805-431-000 Antenna, S-UHF, 1/4 Wave Ground Plane 805-511-001 Antenna, 400 MHz UHF, Whip 2100 accessories 067265 Adapter cable (to cable)

  • Page 242: Default Settings

    MobileLAN access 21XX System Manual Default Settings The factory default settings for the access points are listed in this section. You can record the settings for your installation in each table for reference. TCP/IP Settings Menu Defaults Parameter Name Range Default Your Site? IP Address...

  • Page 243: Global Flooding Menu Defaults

    Specifications and Default Settings Global Flooding Menu Defaults Parameter Name Range Default Your Site? Multicast Flood Mode Universal, Hierarchical, Hierarchical Disabled Multicast Outbound to Enabled/Disabled Enabled Terminals Multicast Outbound to Enabled/Set locally Set locally Secondary LANs Unicast Flood Mode Universal, Hierarchical, Disabled Disabled Unicast Outbound to...

  • Page 244: Ethernet Configuration Menu Defaults

    MobileLAN access 21XX System Manual Global RF Parameters Menu Defaults (continued) Parameter Name Range Default Your Site? RFC1042 Types to Pass Through Two sets of hexadecimal 80 F3 pairs 00 through FF. Two sets of hexadecimal 81 37 pairs 00 through FF. 3 through 20 Two sets of hexadecimal 00 00...

  • Page 245: Ethernet Advanced Filters Menu Defaults

    Specifications and Default Settings Ethernet Filters Menu Defaults (continued) Parameter Name Range Default Your Site? Customizable Subtype Filters Action Pass/Drop Pass SubType DIX-IP-TCP-Port, DIX-IP-TCP-Port DIX-IP-UDP-Port, DIX-IP-Protocol, DIX-IPX-Socket, DIX-EtherType, SNAP-IP-TCP-Port, SNAP -IP-UDP-Port, SNAP -IP-Protocol, SNAP -IPX-Socket, SNAP -EtherType, 802.3-IPX-Socket, 802.2 -IPX-Socket, 802.2-SAP Value Two sets of hexadecimal...

  • Page 246: Ip Tunnels Menu Defaults

    MobileLAN access 21XX System Manual IP Tunnels Menu Defaults Parameter Name Range Default Your Site? Port Control Enabled/Disabled Enabled Mode Listen/Originate If Root Listen IGMP Enabled/Disabled Enabled Multicast Address 4 nodes, 0 to 255 224.0.1.65 Tunnel Filters Menu Defaults Parameter Name Range Default Your Site?

  • Page 247: Network Management Menu Defaults

    1 to 15 characters Secret IDRS IDRS Enabled/Disabled Disabled IDRS Server Address 4 nodes, 0 to 255 0.0.0.0 IDRS Scope 1 to 15 characters INTERMEC Security Menu Defaults Parameter Name Range Default Your Site? Telnet Access Enabled/Disabled Enabled Browser Access Enabled/Disabled...

  • Page 248: 802.1X Menu Defaults

    Unencryption Allowed/ Encryption Encryption Required Required WEP Transmit Key 1, 2, 3, 4 WEP Key 1 5 or 13 characters Intermec WEP Key 2 5 or 13 characters (blank) WEP Key 3 5 or 13 characters (blank) WEP Key 4...

  • Page 249: Ieee 802.11B Radio Menu Defaults

    Parameter Name Range Default Your Site? Port Control Enabled/Disabled Enabled SSID (Network Name) 0 to 32 characters INTERMEC Frequency Channel 1 to 14, Channel 3, 2400 to 2500 MHz 2422 MHz Data/Voice Settings Data Traffic Only, Data Data Traffic only...

  • Page 250: Ieee 802.11A Radio Menu Defaults

    Parameter Name Range Default Your Site? Port Control Enabled/Disabled Enabled SSID (Network Name) 0 to 32 characters INTERMEC Speed Mode 802.11 compliant, Turbo 802.11 compliant Frequency Channel 36, 40, 44, 48, Channel 36, 5180 52, 56, 60, 64 Advanced Configuration...

  • Page 251: Openair Radio Menu Defaults

    Specifications and Default Settings OpenAir Radio Menu Defaults Parameter Name Range Default Your Site? Port Control Enabled/Disabled Enabled Security ID 1 to 20 characters (blank) Channel 1 to 15 Subchannel 1 to 15 MAC Configuration Default, Interference, Default Throughput, or Manual Wireless Bridging Node Type Master/Station...
  • Page 252 MobileLAN access 21XX System Manual 902 MHz Radio Configuration Menu Defaults Parameter Name Range Default Your Site? Port Control Enabled/Disabled Enabled Mode-Channel Depends on country DS 225K-Channel Multicast Filter Enabled/Disabled Disabled File Name FALCON_D.BIN FALCON_D.BIN Hello Period 1, 2, or 3 seconds 1 second S-UHF Radio Configuration Menu Defaults Parameter Name...
  • Page 253 Glossary...
  • Page 254 test...
  • Page 255 Glossary ARP (Address Resolution Protocol) Address Resolution Protocol. The protocol used by TCP/IP networks to relate IP addresses with the physical network addresses of network interfaces. BFSK (Binary Frequency Shift Key) A broadcasting method that lengthens the range but halves the throughput as compared to the QFSK method.
  • Page 256 An Internet standard stack protocol that allows dynamic distribution of IP address and other configuration information to IP hosts on a network. Implementation of the DHCP client in Intermec network devices simplifies installation because the devices automatically receive IP addresses from a DHCP server on the network.
  • Page 257 This repository stores network traffic information that SNMP management programs collect. Your network administrator can use management software interacting with the MIB to obtain information about network activity. Contact your local Intermec representative to learn how to obtain a copy of the MIB for the access point.
  • Page 258 MobileLAN access 21XX System Manual multicast address A form of broadcast address through which copies of the frame are delivered to a subset of all possible destinations that have a common multicast address. NAT (Network Address Translation) A mechanism for reducing the need for different IP addresses. NAT allows an organization with IP addresses that are not unique to connect to the network by translating those addresses into routable address space.
  • Page 259 Glossary remote IP subnet Also called a secondary LAN. The IP subnet that does not contain the root access point, but communicates with the primary LAN through an IP tunnel. root access point The access point with the highest root priority becomes the root of the network spanning tree.
  • Page 260 MobileLAN access 21XX System Manual spanning tree A form of network organization in which each device on the network has only one path to the root. The access points automatically configure into a self-organized network that provides efficient, loop-free forwarding of frames through the network. subnet A single member of the collection of hardware networks that compose an IP network.
  • Page 261 Index...
  • Page 263 Index 802.11a radio Numbers Advanced Configuration screen, 5-13 100BaseFX, See fiber optic. configuring, 5-10 10BaseT port, 1-8 advanced parameters, 5-13 10BaseT/100BaseTx port, 1-8 parameters, described, 5-11, 5-14 2100 specifications, A-8 attaching an antenna, 2-9 worldwide frequencies, 5-12 connecting to power, 2-10 802.11b radio connecting to the network, 2-9, 2-15 Advanced Configuration screen, 5-7...
  • Page 264 MobileLAN access 21XX System Manual Access Point Login screen, 1-22 advanced filters access points configuring, 3-20 AP monitor, using, 8-3 to 8-11 example, 3-23 architecture, 4-6 advanced parameters, configuring configuring, 1-16 for 802.11a radio, 5-13 as a DHCP client, 3-5 for 802.11b radio, 5-7 as a DHCP server, 3-6 antenna bracket option, using with the 2101, 2-6...
  • Page 265 Index Automated Software Download screen (continued) Community Strings screen, 7-4 Server IP Address field, 7-34 defaults, A-17 Start Time field, 7-34 SNMP Read Community field, 7-4 SNMP Secret Community field, 7-4 SNMP Write Community field, 7-4 community strings, SNMP, configuring, 7-3 Basic Rate field, 5-8, 5-14 comparing IP tunnels to mobile IP, 4-33 baud rate, setting, 8-5...
  • Page 266 MobileLAN access 21XX System Manual connecting (continued) DHCP Server Setup screen, 3-7 2101 DNS Address field, 3-7 to fiber optic network, 2-15 High Address field, 3-7 to network, 2-8 Lease Time field, 3-8 to power, 2-8 Low Address field, 3-7 2102 directional antenna, 2-21 to network, 2-14...
  • Page 267 Index Ethernet (continued) fiber optic, 1-8 connecting configuring settings, 3-11 2100, 2-9 connecting 2101, 2-8 to an MT-RJ network, 2-15 2102, 2-14 to an SC network, 2-16 2106, 2-14 to an ST network, 2-17 data rate specifications, A-3, A-4 2100, A-4 using to connect the access points, 2-15 2101, A-3 File Name field, 5-21, 5-23...
  • Page 268 MobileLAN access 21XX System Manual frequencies HyperTerminal, See communications program. 802.11a radio, 5-12 802.11b radio, 5-6 frequency band IAPP Frame Type field, 4-4 902 MHz radio, A-9 IAPP Secret Key field, 6-12 IEEE 802.11a radio, A-8 IAPP Security Context Hand Off field, 6-12 IEEE 802.11b radio, A-7 ICMP Configuration field, 6-4 S-UHF radio, A-9...
  • Page 269 Index Intermec Device Registration Service, See IDRS. 2106 illustration, 1-7 Intermec Technologies Corporation lighting sequence, understanding, 7-6 contacting, ii Power, 1-6 Web site address, xv Radio, 1-6 Intermec Technologies Corporation, contacting, See technical Root/error, 1-6 support. summary, 1-6 Internal RADIUS Server screen, 6-8...
  • Page 270 MobileLAN access 21XX System Manual Manual MAC Parameters screen (continued) Fragment QFSK Retry field, 5-19 Fragment Size field, 5-18 definition, G-6 Hop Period field, 5-18 understanding, 3-8 Normal Ack Retry field, 5-19 NAT server, configuring the access point, 3-9 Normal QFSK Retry field, 5-19 network address translation, See NAT.
  • Page 271 Index Passwords screen (continued) power, connecting RADIUS Authorization field, 6-7 2100, 2-10 RADIUS Server IP Address fields, 6-7 2101, 2-8 RADIUS Server Secret Key fields, 6-7 2102, 2-14 Read Only Password field, 6-7 2106, 2-14 Service Password field, 6-7 Predefined Subtype Filters screen, 3-17, 4-27 User Name field, 6-7 predefined subtype filters, using, 3-17, 4-27 patent information, xv...
  • Page 272 MobileLAN access 21XX System Manual RFC1042 Types to Pass Through field, 4-13 Service Password field, 6-7 RFC1042/DIX Conversion field, 4-13 setting roaming, using access points, 1-12 filter expressions, 3-21 ROM monitor, See AP monitor. filter values, 3-20 root access point MAC configuration parameters manually, 5-17 definition, G-7 Simple Network Management Protocol, See SNMP.
  • Page 273 IP Subnet Mask field, 3-4 SNMP agent, A-3, A-4, A-5, A-6 technical support software upgrades, A-3, A-4, A-5, A-6 contacting Intermec Technologies Corporation, 7-13 S-UHF radio, A-9 Web site address, xv temperature, A-3, A-4, A-5, A-6 Telnet Access field, 6-4...
  • Page 274 MobileLAN access 21XX System Manual Unicast Outbound to Terminals field, 4-11 positioning OpenAir antennas, 2-21 unsupported DHCP server options, 3-8 using, 1-15 upgrade server, See MobileLAN access Utility. warranty information, xiii Upgrade Software screen, 7-27 Web browser interface, enabling access, 6-4 UPGRADE.DNL, 7-31 Web browser interface, using, 1-16 upgrading access points, 7-24...
  • Page 275 Corporate Headquarters 6001 36th Avenue West Everett, Washington 98203 tel 425.348.2600 fax 425.355.9551 www.intermec.com MobileLAN™access 21XX System Manual *067150-008* *067150-008*...
