MobileLAN access WA22/2101 Cubicle

Bracket Instruction Sheet

This instruction sheet explains how to mount the

MobileLANaccess WA22 or the MobileLANaccess 2101 on

a cubicle wall using this cubicle bracket kit (P/N 069926) with

the mounting bracket that shipped with the access point. Note

these important points:

• The cubicle bracket fits cubicle walls that are 4.6 to 9.1 cm

(1.8 to 3.6 in) thick.

• These instructions assume that you have inserted the shoulder

screws that ship with the mounting bracket into the brass

inserts on the back of the access point. For instructions on

how to insert the shoulder screws, see the quick start guide

that shipped with your access point.

Mounting

bracket

Adjustment

knob

Cubicle

bracket

Cubicle

wall

2101I001.eps
