Intermittent (60 Sec Overload); Max. Input Current; (60 Sec Overload); Max. Pre-Fuses [A] - Danfoss VLT AutomationDrive FC 300 Design Manual

FC 300 Design Guide
Mains Supply 3 x 525- 690 VAC
FC 302
High/ Normal Load*
Typical Shaft output
at 550 V [kW]
Typical Shaft output
at 575 V [HP]
Typical Shaft output
at 690 V [kW]
Enclosure IP21, 54
Enclosure IP00
Output current
Continuous
(at 550 V) [A]
Intermittent (60 sec
overload)
(at 550 V) [A]
Continuous
(at 575/ 690 V) [A]
Intermittent (60 sec
overload)
(at 575/ 690 V) [A]
Continuous KVA
(at 550 V) [KVA]
Continuous KVA
(at 575 V) [KVA]
Continuous KVA
(at 690 V) [KVA]

Max. input current

Continuous
(at 550 V ) [A]
Continuous
(at 575 V) [A]
Continuous
(at 690 V) [A]
Max.
[mm 2 (AWG)]

Max. pre-fuses [A]

Estimated
loss
at rated max. load
[W] 4)

Weight,

enclosure IP21, IP
54 [kg]
Weight,
enclosure IP00 [kg]
Efficiency
* High overload = 160% torque during 60 s, Normal overload = 110% torque during 60 s
P110
HO NO HO
90 110 110
125 150 150
110 132 132
D1
D3
137 162 162
206 178 243
131 155 155
197 171 233
131 154 154
130 154 154
157 185 185
130 158 158
124 151 151
128 155 155
cable size
2 x 70 (2 x 2/0)
1
315
power
2664 3114 2953
96
82
4) 0.98
MG.33.BA.02 - VLT ® is a registered Danfoss trademark
P132 P160 P200
NO HO NO HO
132 132 160 160
200 200 250 250
160 160 200 200
D1 D2 D2
D3 D4 D4
201 201 253 253
221 302 278 380
192 192 242 242
211 288 266 363
191 191 241 241
191 191 241 241
229 229 289 289
198 198 245 245
189 189 234 234
197 197 240 240
2 x 185 (2 x 350 mcm)
350 350 400
3612 3451 4292 4275
104 125 136
91 112 123
0.98 0.98 0.98
4. FC 300 Selection
P250 P315
NO HO NO HO NO
200 200 250 250 315
300 300 350 350 400
250 250 315 315 400
D2 D2
D4 D4
303 303 360 360 418
333 455 396 540 460
290 290 344 344 400
319 435 378 516 440
289 289 343 343 398
289 289 343 343 398
347 347 411 411 478
299 299 355 355 408
286 286 339 339 390
296 296 352 352 400
500 550
5156 4875 5821 5185 6149
151 165
138 151
0.98 0.98
4
63
