1. How to Read this Design Guide

1.1.3. Abbreviations

1
Alternating current
American wire gauge
Ampere/AMP
Automatic Motor Adaptation
Current limit
Degrees Celsius
Direct current
Drive Dependent
Electro Magnetic Compatibility
Electronic Thermal Relay
drive
Gram
Hertz
Kilohertz
Local Control Panel
Meter
Millihenry Inductance
Milliampere
Millisecond
Minute
Motion Control Tool
Nanofarad
Newton Meters
Nominal motor current
Nominal motor frequency
Nominal motor power
Nominal motor voltage
Parameter
Protective Extra Low Voltage
Printed Circuit Board
Rated Inverter Output Current
Revolutions Per Minute
Second
Torque limit
Volts

1.1.4. Definitions

Frequency converter:
D-TYPE
Size and type of the connected frequency converter (dependencies).
I
VLT,MAX
The maximum output current.
I
VLT,N
The rated output current supplied by the frequency converter.
U
VLT, MAX
The maximum output voltage.
Input:
Control command
You can start and stop the connected motor by means of LCP and the
digital inputs.
Functions are divided into two groups.
Functions in group 1 have higher priority than functions in group 2.
Motor:
f
JOG
The motor frequency when the jog function is activated (via digital terminals).
f
M
The motor frequency.
f
MAX
The maximum motor frequency.
f
MIN
The minimum motor frequency.
6
Group 1
Group 2
MG.33.BA.02 - VLT ® is a registered Danfoss trademark
FC 300 Design Guide
AC
AWG
A
AMA
I
LIM
°C
DC
D-TYPE
EMC
ETR
FC
g
Hz
kHz
LCP
m
mH
mA
ms
min
MCT
nF
Nm
I
M,N
f
M,N
P
M,N
U
M,N
par.
PELV
PCB
I
INV
RPM
s
T
LIM
V
Reset, Coasting stop, Reset and Coast-
ing stop, Quick-stop, DC braking, Stop
and the "Off" key.
Start, Pulse start, Reversing, Start re-
versing, Jog and Freeze output
