6.8.4. Relay Connection

To set relay output, see par. group 5-4* Relays.
6
Terminals for relay connection
(Frame sizes A1, A2 and A3).
Terminals for relay connection
(Frame sizes C1 and C2).
136
No. 01 - 02
01 - 03
04 - 05
04 - 06
Terminals for relay connection
(Frame sizes A5, B1 and B2).
Relay connection terminals for D and E enclosures are
shown in the section
closures
MG.33.BA.02 - VLT ® is a registered Danfoss trademark
FC 300 Design Guide
make (normally open)
break (normally closed)
make (normally open)
break (normally closed)
Electrical Installation - D and E en-
