3. Introduction to FC 300
Enclosure type
3
Enclosure IP
protection NEMA
Rated
power
Enclosure type
Enclosure IP
protection NEMA
Rated
power
18
D1 D2
21/54
Type 1/ Type 12
90-110 kW at 400 V 132-200 kW at 400 V
(380-500 V) (380-500 V)
37-132 kW at 690 V 160-315 kW at 690 V
(525-690 V) (525-690 V)
E1 E2
21/54
Type 1/ Type 12
250-400 kW at 400 V 250-400 kW at 400 V
(380-500 V) (380-500 V)
355-560 kW at 690 V 355-560 kW at 690 V
(525-690 V) (525-690 V)
MG.33.BA.02 - VLT
D3
21/54
Type 1/ Type 12 Chassis
90-110 kW at 400 V
(380-500 V)
37-132 kW at 690 V
(525-690 V)
00
Chassis
® is a registered Danfoss trademark
FC 300 Design Guide
D4
00 00
Chassis
132-200 kW at 400 V
(380-500 V)
160-315 kW at 690 V
(525-690 V)
