4. FC 300 Selection
Mains Supply 3 x 380 - 500 VAC
FC 302
High/ Normal Load*
Output current
4
Max. input current
* High overload = 160% torque during 60 s, Normal overload = 110% torque during 60 s
58
P90K
HO
Typical Shaft output at
90
400 V [kW]
Typical Shaft output at
125
460 V [HP]
Typical Shaft output at
110
500 V [kW]
Enclosure IP21, 54 D1
Enclosure IP00 D3
Continuous
177
(at 400 V) [A]
Intermittent (60 sec
overload) 266
(at 400 V) [A]
Continuous
160
(at 460/ 500 V) [A]
Intermittent (60 sec
overload) 240
(at 460/ 500 V) [A]
Continuous KVA
123
(at 400 V) [KVA]
Continuous KVA
127
(at 460 V) [KVA]
Continuous KVA
139
(at 500 V) [KVA]
Continuous
171
(at 400 V ) [A]
Continuous
154
(at 460/ 500 V) [A]
2
Max. cable size [mm
(AWG 2) )]
Max. pre-fuses [A] 1 300
Estimated power loss
at rated max. load [W]
2641
4)
Weight,
enclosure IP21, IP 54 96
[kg]
Weight,
82
enclosure IP00 [kg]
Efficiency 4) 0.97
MG.33.BA.02 - VLT
P110 P132
NO HO NO HO
110 110 132 132
150 150 200 200
132 132 160 160
D1
D3
212 212 260 260
233 318 286 390
190 190 240 240
209 285 264 360
147 147 180 180
151 151 191 191
165 165 208 208
204 204 251 251
183 183 231 231
2 x 70
(2 x 2/0)
350
3234 2995 3782 3425
104
91
0.97
® is a registered Danfoss trademark
FC 300 Design Guide
P160
NO HO NO HO
160 160 200 200
250 250 300 300
200 200 250 250
D2 D2
D4 D4
315 315 395 395
347 473 435 593
302 302 361 361
332 453 397 542
218 218 274 274
241 241 288 288
262 262 313 313
304 304 381 381
291 291 348 348
2 x 185
(2 x 350 mcm)
400 500
4213 3910 5119 4625
125 136
112 123
0.97 0.98
P200
NO
250
350
315
D2
D4
480
528
443
487
333
353
384
463
427
600
5893
151
138
0.98
