Communication Interfaces
to set the baudrate.
Data bit: 8
Stop bit: 1
Parity bit: (none,even,odd)
EVEN 8 data bits have even parity
ODD 8 data bits have odd parity
NONE 8 data bits have no parity
Native machine address: ( 0 ~31, factory default is 0)
Start Bit 8 Data Bits Parity=None Stop Bit

5.3USB Interface

Connect the load and the computer using a cable with two USB interfaces
(each end). All functions of the load can be programmed via USB.
After connecting the load and computer by USB, you need to install IT-E122
driver or IT-E132 driver ( see in ITECH CD or contact ITECH agent). The device
manager of PC will display 'Prolific USB-to-Serial COM Port' after installing.
Notes: Only IT8514B+/8514C+/IT8516C+ models have the USB commucation
interface. Just use USB line to connect in commucation. ( Please don't connect
DB9 interface at the same time). Don't need to set the menu.
