Supplementary Characteristics - ITech IT8500plus Series User Manual

OPP
Protection
OCP
Protection
OVP
Protection
OTP
Protection
current( CC )
voltage( CV )
Short
resistance( C
R )
input
Impendanc
e
Dimension
The voltage/current input is no less than 10% FS
*1
The scope of read-back resistance is
*2
IT8514B+/14C+/16C+: ( 1/(1/R+(1/R)*0.02%+0.08),1/(1/R-(1/R)*0.02%-0.08) )
The voltage/current input is no less than 10% FS
*3
*4 .Ascending/descending slope: 10%-90% current ascending slope from 0 to
maximum current
*5 Minimum rise time: 10%-90% current rise time
The above specifications may be subject to change without prior notice.
*

Supplementary Characteristics


Memory capacity:100 registeres
Suggested calibration frequency:Once a year

AC input level(A transfer switch is selectable on the rear panel)
Option Opt.1: 220V ±10%
Option Opt.2: 110V ±10%

Cooling type
Intelligent fans

Fans working principle:
Fans running speed is determined by radiator temperature.When
temperature reaches 40 ℃,fans start to work and intellig ently adjust its
speed with temperature variation.
Protection range
≒1550W
≒6.7A
≒530V
≒85℃
Specification
≒6.7/6A
0V
≒30mΩ
150KΩ
436.5mm*88.2mm*463.5mm
:( 1/(1/R+(1/R)*0.01%+0.08),1/(1/R-(1/R)*0.01%-0.08) )
Copyright © Itech Electronics Co., Ltd.
≒67A ≒26A
≒67/60A ≒26/24A
0V 0V
≒30mΩ ≒5mΩ
436.5mm*176mm*463.5mm
50Hz/60Hz
50Hz/60Hz
Specifications
≒3050W
≒260A
≒125V
≒85℃
≒260/240A
0V
≒5mΩ
150KΩ
