Chapter2 Quick Start; Brief Introduction - ITech IT8500plus Series User Manual

This chapter introduces the front panel, the rear panel, key functions and VFD
display function of the electronic load, make sure that you can quickly know the
appearance, instruction and the key function before you operate the load, Help
you make better use of this series of electronic load.

2.1 Brief Introduction

IT8500plus series DC electronic loads are single channel programmable
electronic load which can provide multiple solutions according to the
requirements of your design and test. This series have international advanced
functions and features.

High-visibility vacuum fluorescent display (VFD)

Measurement resolution: 0.1mV,0.1mA

Voltage and current Measurement speed: up to 40KHZ

Four operation modes:CV(Constant Voltage),CC,CR,CW

Battery test function

OCP test , OVP test

Auto test function:

Short circuit function

Remote Sense function

Memory capacity to save/recall setting parameters: 100 registers

Intelligent fans

Build-in Buzzer as alarm signal

Power off memory function

Rotary knob, making the operation more convenient

Measure test function,test the rising/dropping time of the voltage

List modes
Model
IT8511+
IT8511A+
IT8511B+
IT8512+
IT8512A+
IT8512B+
IT8512C+
IT8512H+
IT8513A+
IT8513C+
IT8514B+
IT8514C+
IT8516C+

Chapter2 Quick Start

Voltage Current
120V 30A
150V 30A
500V 10A
120V 30A
150V 30A
500V 15A
120V 60A
800V 5A
150V 60A
120V 120A
500V 60A
120V 240A
120V 240A
Copyright © Itech Electronics Co., Ltd.
Power Communication
Interface
150W DB9(TTL)
150W DB9(TTL)
150W DB9(TTL)
300W DB9(TTL)
300W DB9(TTL)
300W DB9(TTL)
300W DB9(TTL)
300W DB9(TTL)
400W DB9(TTL)
600W DB9(TTL)
1500W USB/RS232
1500W standard USB/RS232
3000W Standard USB/RS232
Quick Start
6
