[ Enter ] to confirm.
6 Save the battery test to specified file
7 Press [ Enter ] to confirm
(3)Time-out Cut Off
Step Operation
Press [ Shift ]+ [ 5 ] (Battery),set current range
1
2 Set discharge current,for example 2A
3 Set the stop voltage to 0V, then press [ Enter ] to
confirm.
4 Set the stop capability to maximum 999.999AH,
press [ Enter ] to confirm.
5 Set the stop timer, for example, 3800S, press
[ Enter ] to confirm.
6 Save the battery test to specified file
7 Press [ Enter ] to confirm
(4) Any of the Three Conditions Cut Off
Step Operation
Press [ Shift ]+ [ 5 ] (Battery),set current range
1
2 Set discharge current,for example 2A
3 Set the stop voltage as needed,for example,2V,then
press [ Enter ] to confirm.
4 Set the stop capbility as needed,for example,7AH,then
press [ Enter ] to confirm.
5 Set the stop timer as needed,for example,3800S,then
press [ Enter ] to confirm.
6 Save the battery test to specified file
7 Press [ Enter ] to confirm
(5)Go into Battery Test Mode
Operation
1.Press [ Shift ]+ [ 8 ] (system) enter into
sysmtem menu
2.Press right key,select RUNMODE and
confirm with [ Enter ] button
3.Press direction
OCP_TEST,Press [ Enter ] to confirm.
4,Press [ ESC ] button to quit menu set
(6)Start Battery Test
Press [
process will be auto terminated when stop conditions are reached.
(7)Recall Battery File
Press [ Shift ] + [ Enter ] button to select programe file,the panel displays
"RECALL BATTERY 1.Enter the file name(1-10),press [ Enter ] button to
Display on front pannel
0.0000V
POWER-ON
0.0000V
RUN <NORMAL
key to select 0.0000V
RUN <BATTERY
0.0000V
] (trigger) to provide a signal to start battery test.The discharing
Copyright © Itech Electronics Co., Ltd.
Functions and Characteristics
0.0000V 0.000A
SAVE BATT FILE 1(1-10)
0.0000V 0.000A
0.00W I = 2.00A
Off cc
Display
0.0000V 0.000A
RANGE = 0.00A
CURRENT = 2.000A
STOP VOLT=0V
STOP CAP=999.999AH
STOP TIMER=3800S
0.0000V 0.000A
SAVE BATT FILE 1(1-10)
0.0000V 0.000A
0.00W I = 2.00A
Off cc
Display
0.0000V
RANGE = 0.00A
CURRENT = 2.000A
STOP VOLT=2V
STOP CAP=7AH
STOP TIMER=3800S
0.0000V
SAVE BATT FILE 1(1-10)
0.0000V
0.00W
Off cc
0.000A
BUZZER
0.000A
0.000A
0.000A
0S 0.000AH
0.000A
0.000A
0.000A
I = 2.00A
