ITech IT8500plus Series User Manual page 48

Tpf is the delay time for a step
PROGRAM 1 1
Sequence
Save Group 1
PROGRAM 2 1
Sequence
Save Group 11
PROGRAM 10 1
Sequence
Save Group 91
Set the steps of a test file in the example
CC Mode, 1.2A, Voltage Range 4.4V~4.6V
Step
Set stop conditions: COMP means
15
stop test when all the steps are
completed, FAILURE means stop
test when the testing fails. Press
[Enter] key to confirm.
16 Select the test file to link if you'd like
to. The linked file must be saved
before. 0 stands for not linking to
other files. Press [Enter] key to
confirm.
2 3
2 3
2 3
12 13
2 3
92 93
17 Save the edited files in EEPROM,
you can save up to 10 groups of
files, e.g please press [1] to save
the edited file in group 1, and then
press [Enter] to confirm.
18 Select a operation mode and then
press [Shift]+[CV] to set related
parameters
19 Edit the three steps of the test file,
details refer to below procedure.
After all the steps are set ,
Press [ESC] to exit setup, and
then press [Shift]+[4] to save.
You need to recall the test file before runing it
Operation
1 Press [CC]
[Shift) (Setup)
+[CV]
the setting interface
2 Set the current
Enter]
[ to confirm
3 set the upper limit of voltage,
Enter]
press [ to confirm
4 Set the lower limit of voltage,
Enter]
press [ to confirm
5 Set the rise speed of current,
Enter]
press [ to confirm
6 Set the fall speed of current,
Enter]
press [ to confirm
7 Finish the setup
Copyright © Itech Electronics Co., Ltd.
4 5 6
4 5 6
4 5 6
14 15 16
4 5 6
94 95 96
VFD Display
button,and then RANGE=30.000A
CC
to enter
range,press RANGE =1.2A
CC
HIGH=4.6V
CC
LOW=4.4V
CC
UP=1A/uS
CC
DOWN=1A/uS
CC
10.0000V
0.00W
Basic Operation
STOP COMP
FAILURE
CHAIN PROGRAM
=0(0-10)
7 8 9
7 8 9
7 8 9
17 18 19
7 8 9
97 98 99
SAVE PROGRAM
=1(1-10)
10.0000V 0.0000A
0.00W CC=1.000A
0.000A
CC=0.000A
10
10
10
20
10
100
39
